Peitian AIR20SC-1000

Peitian Robot

Industrial-Robot China

ChinaReleased

★Not rated yet

Compare

Sources:

cdn.robotaigeek.com

Industries:

Research Manufacturing

Uses:

Assembly Pick-and-placeElectronics assemblypick-and-placemachine tool loading and unloadingpackaging

Price:

Not announced

DESCRIPTION

Peitian AIR20SC-1000 is an Industrial-Robot from Peitian Robot. It is built for Assembly, Pick-and-place, Electronics assembly. Key figures: 54 kg, 10 kg payload, 1000 mm reach, 4 degrees of freedom.

The AIR20SC-1000 is a four-axis SCARA from Peitian's AIR range, reaching 1000 mm and rated for 10 kg with a 20 kg maximum. SCARA geometry trades the full articulation of a six-axis arm for stiffness in the vertical direction and speed in the horizontal plane, which is why this class dominates electronics assembly, pick-and-place and machine tending rather than welding or finishing. At 54 kg the arm itself is light enough to mount on a bench or a line frame. Peitian pairs it with its own inCube2S-20 controller cabinet. Ingress protection is IP30 / IP54.

FEATURES

SCARA four-axis industrial robot arm
Rated payload 10 kg with a maximum payload of 20 kg
Axis 3 vertical stroke available in 200 / 300 / 400 / 600 mm options
Maximum reach 1000 mm
Manipulator weight 54 kg
Ingress protection IP30 / IP54
Mounting: Floor / ceiling
Compatible controller cabinets: inCube2S-20
Working range Axis 1 -135°/+135°
Axis 2 -135°/+135°
Axis 4 -135°/+135°
Axis 4 wrist -135°/+135°
Axis 5 bend -360°/+360°
Axis 6 turn -360°/+360°
Rotation rate Axis 1 rotation 1300°/s
Axis 2 arm 1300°/s
Ambient temperature 0 to 45 degrees Celsius, humidity up to 95% non-condensing, altitude up to 1000 m
No corrosive, flammable or explosive gases permitted in the operating environment

TECHNICAL SPECIFICATIONS

Physical
Weight	54 kg
Payload	10 kg
Reach	1 m
Mobility
Movement Type	Stationary
Degrees of Freedom	4
Manipulation	High
Environment	Industrial indoor use, 0 to 45 degrees Celsius, humidity up to 95% non-condensing, altitude up to 1000 m; no corrosive, flammable or explosive gases
Actuators	4-axis SCARA four-axis manipulator, mounted Floor or ceiling
Sensing & Compute
Software / AI	Driven by Peitian inCube2S-20 controller cabinets

Manufacturer-sourcedThird-party sourcedUnsourcedSource status is based on this robot's listed sources.

ROBOT FORUMS

Loading forums...

TECHNICAL SPECIFICATIONS

Physical
Weight	54 kg
Payload	10 kg
Reach	1 m
Mobility
Movement Type	Stationary
Degrees of Freedom	4
Manipulation	High
Environment	Industrial indoor use, 0 to 45 degrees Celsius, humidity up to 95% non-condensing, altitude up to 1000 m; no corrosive, flammable or explosive gases
Actuators	4-axis SCARA four-axis manipulator, mounted Floor or ceiling
Sensing & Compute
Software / AI	Driven by Peitian inCube2S-20 controller cabinets

Manufacturer-sourcedThird-party sourcedUnsourcedSource status is based on this robot's listed sources.

FREQUENTLY ASKED QUESTIONS

What is the Peitian AIR20SC-1000?

Who makes the Peitian AIR20SC-1000?

The Peitian AIR20SC-1000 is made by Peitian Robot, a robotics company based in China.

How much does the Peitian AIR20SC-1000 cost?

Peitian Robot has not publicly announced pricing for the Peitian AIR20SC-1000. You can enquire through RobotAIGeek for current pricing.

What is the Peitian AIR20SC-1000 used for?

The Peitian AIR20SC-1000 is designed for assembly, pick-and-place, electronics assembly, and pick-and-place. It is used in research and manufacturing settings.
