Guoxing RXR-Q200L

Shandong Guoxing Intelligent Technology

Mobile-Robots China

ChinaReleased

★Not rated yet

Compare

Sources:

gxsuprobot.com

Industries:

Energy Security & Patrol

Uses:

Inspection TransportFlood drainagebasement and underpass dewateringinternal drainage and water supplydisaster response water management

Price:

Not announced

DESCRIPTION

Guoxing RXR-Q200L is a Mobile-Robots from Shandong Guoxing Intelligent Technology. It is built for Inspection, Transport, Flood drainage. Key figures: 850 kg, 300 min runtime.

The RXR-Q200L is a pump on wheels that can swim. Its amphibious all-terrain wheeled chassis travels on muddy and low-lying roads and into water, and its dual-row high-flow axial pumps move up to 720 cubic metres an hour — 200 litres a second — lifting six metres and drawing from as shallow as 220 mm, or 120 mm with the interchangeable elbows fitted. That last figure is what makes it useful in a flooded basement or underpass where the water is too shallow for a conventional pump to prime. It drags its own hoses up to 300 metres into flooded areas, so the machine goes to the water rather than the crew carrying suction lines in. An imported engine and hydraulic motor drive it, the turning radius is extremely small for on-the-spot turning, and it handles particles up to 25 mm so debris-laden flood water does not block it.

FEATURES

Amphibious all-terrain wheeled drive, suitable for both land and water
Under 2100 x 1400 x 1300 mm and under 850 kg
Dual-row high-flow axial pumps with a maximum flow rate of 720 m³/h, equal to 200 L/s
Drainage lift of 6 metres or more and draft depth of 500 mm or more
Minimum water intake depth of 220 mm, reduced to 120 mm with the interchangeable elbows fitted
Maximum particle diameter of 25 mm for debris-laden water
Capable of directly dragging water hoses into flooded areas up to 300 metres away
Imported engine and hydraulic motor with hydraulic power unit and hydraulic piping system
Operating speed of 1.5 m/s or more
maximum obstacle crossing 220 mm or more
maximum climbing 60% or more
Traction of 4 kN or more
braking distance 0.3 m or less
straight-line deviation 3% or less
Extremely small turning radius allowing on-the-spot turning
Working time of 5 hours or more
remote control distance 200 m
IP66 protection with upper IP54
Compact and lightweight, compatible with existing water supply and drainage equipment

TECHNICAL SPECIFICATIONS

Verified

Physical
Weight	850 kg
Dimensions	L 2.1 m × W 1.4 m × H 1.3 m
Mobility
Movement Type	Wheeled
Speed	5.4 km/h
Environment	Land and water, muddy and low-lying roads, flooded basements; IP66 with upper IP54
Actuators	Amphibious all-terrain wheeled chassis with an imported engine, hydraulic power unit and dual-row high-flow axial pumps
Power
Battery Life	≥5 h

Manufacturer-sourcedThird-party sourcedUnsourcedSource status is based on this robot's listed sources.

ROBOT FORUMS

Loading forums...

TECHNICAL SPECIFICATIONS

Verified

Physical
Weight	850 kg
Dimensions	L 2.1 m × W 1.4 m × H 1.3 m
Mobility
Movement Type	Wheeled
Speed	5.4 km/h
Environment	Land and water, muddy and low-lying roads, flooded basements; IP66 with upper IP54
Actuators	Amphibious all-terrain wheeled chassis with an imported engine, hydraulic power unit and dual-row high-flow axial pumps
Power
Battery Life	≥5 h

Manufacturer-sourcedThird-party sourcedUnsourcedSource status is based on this robot's listed sources.

FREQUENTLY ASKED QUESTIONS

What is the Guoxing RXR-Q200L?

Who makes the Guoxing RXR-Q200L?

The Guoxing RXR-Q200L is made by Shandong Guoxing Intelligent Technology, a robotics company based in China.

How much does the Guoxing RXR-Q200L cost?

Shandong Guoxing Intelligent Technology has not publicly announced pricing for the Guoxing RXR-Q200L. You can enquire through RobotAIGeek for current pricing.

What is the Guoxing RXR-Q200L used for?

The Guoxing RXR-Q200L is designed for inspection, transport, flood drainage, and basement and underpass dewatering. It is used in energy and security & patrol settings.
