DESCRIPTION
Guoxing RXR-MC80BD is a Mobile-Robots from Shandong Guoxing Intelligent Technology. It is built for Inspection, Monitoring, Petrochemical plant and refinery fires. Key figures: 800 kg, 300 min runtime, 80 kg payload.
The RXR-MC80BD is Guoxing's flagship explosion-proof firefighting and reconnaissance machine, built to the CB3836-2010 standard and rated Exdib mbIIB+H2 T6 Gb — a marking that includes hydrogen, which is what lets it work around refineries and chemical plants where an ordinary motor would be an ignition source. The whole machine is explosion-proof, not just the enclosure. It carries an imported water cannon flowing 80 L/s of water or foam more than 80 metres, on a mount that rotates and tilts through a full 90 degrees of elevation so it can fight fire in any direction including overhead. A lifting mast raises the sensor head from under 1.5 m to over 1.9 m to sample toxic gas at different heights, and it detects six types of toxic and flammable gas, collects multi-channel imagery, carries an infrared thermal imager to find the seat of a fire through smoke, and speaks two-way with the control centre. It protects itself as much as the crew: a sprinkler head produces a double water curtain for self-cooling in high heat, and it has anti-overturn and anti-collision functions. At up to 800 kg it tows two 80 mm hoses over 100 metres and runs more than five hours.
FEATURES
- Fully explosion-proof machine rated Exdib mbIIB+H2 T6 Gb, built to CB3836-2010
- Up to 1800 x 1000 x 1500 mm and up to 800 kg
- Imported fire water cannon at 80 L/s (±6%), water and foam dual-purpose, range over 80 metres
- Water cannon pitch from -5 to +90 degrees and traverse from -90 to +90 degrees, at 1.0 MPa working pressure
- Obstacle crossing height of 220 mm or more and climbing ability of 70% or more
- Straight speed of 1.5 m/s or more with straight running deviation of 3% or less and braking distance of 0.3 m or less
- Slope operation to 30 degrees or more without rolling over
- anti-overturn and anti-collision functions
- Working time of 5 hours or more, load capacity about 80 kg
- Tows two 80 mm water hoses over 100 metres, with one-click automatic dehydration belt detachment
- Detection of 6 types of toxic and flammable gases
- Infrared thermal imaging camera detecting living organisms, fire source temperature and fire source centre point
- Lifting device raising the sensor head from under 1500 mm to over 1900 mm for gas detection at height
- Multi-channel image collection, two-way voice, dual LED strong lighting and sound-and-light alarm
- Automatic obstacle avoidance and self-cooling double water curtain spray
- IP67 chassis with IP65 body
- remote distance 1000 m
- wireless with redundant control
- Portable 10.1 inch control box, 467 x 366 x 188 mm, under 5 kg, with six units able to work simultaneously without interference
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Weight | 800 kg |
|---|---|
| Dimensions | L 1.8 m × W 1 m × H 1.5 m |
| Payload | 80 kg |
| Mobility | |
| Movement Type | Other |
| Speed | 5.4 km/h |
| Environment | Flammable, toxic, hypoxic and dense-smoke fire scenes; explosive atmospheres including hydrogen; IP67 chassis, IP65 body |
| Actuators | Tracked chassis with high-power DC reduction motor drive and a rotating, tilting water cannon on a lifting sensor mast |
| Power | |
| Battery Life | ≥5 h |
| Sensing & Compute | |
| Sensors | infrared thermal imaging camera, 6-gas toxic and flammable gas detector, multi-channel cameras, temperature and humidity sensor |
ROBOT FORUMS
Loading forums...
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Weight | 800 kg |
|---|---|
| Dimensions | L 1.8 m × W 1 m × H 1.5 m |
| Payload | 80 kg |
| Mobility | |
| Movement Type | Other |
| Speed | 5.4 km/h |
| Environment | Flammable, toxic, hypoxic and dense-smoke fire scenes; explosive atmospheres including hydrogen; IP67 chassis, IP65 body |
| Actuators | Tracked chassis with high-power DC reduction motor drive and a rotating, tilting water cannon on a lifting sensor mast |
| Power | |
| Battery Life | ≥5 h |
| Sensing & Compute | |
| Sensors | infrared thermal imaging camera, 6-gas toxic and flammable gas detector, multi-channel cameras, temperature and humidity sensor |
Images
martti
Image Contributions
Videos
ROBOT FORUMS
Loading forums...
RATINGS
FREQUENTLY ASKED QUESTIONS
What is the Guoxing RXR-MC80BD?
The RXR-MC80BD is Guoxing's flagship explosion-proof firefighting and reconnaissance machine, built to the CB3836-2010 standard and rated Exdib mbIIB+H2 T6 Gb — a marking that includes hydrogen, which is what lets it work around refineries and chemical plants where an ordinary motor would be an ignition source.
Who makes the Guoxing RXR-MC80BD?
The Guoxing RXR-MC80BD is made by Shandong Guoxing Intelligent Technology, a robotics company based in China.
How much does the Guoxing RXR-MC80BD cost?
Shandong Guoxing Intelligent Technology has not publicly announced pricing for the Guoxing RXR-MC80BD. You can enquire through RobotAIGeek for current pricing.
What is the Guoxing RXR-MC80BD used for?
The Guoxing RXR-MC80BD is designed for inspection, monitoring, petrochemical plant and refinery fires, and oil depot fires. It is used in energy, manufacturing, and security & patrol settings.
What is the payload capacity of the Guoxing RXR-MC80BD?
The Guoxing RXR-MC80BD has a payload capacity of 80 kg.
How much does the Guoxing RXR-MC80BD weigh?
The Guoxing RXR-MC80BD weighs 800 kg.
How fast is the Guoxing RXR-MC80BD?
The Guoxing RXR-MC80BD can move at speeds of up to 5.4 km/h.
What is the battery life of the Guoxing RXR-MC80BD?
The Guoxing RXR-MC80BD runs for ≥5 h on a charge.
