DESCRIPTION
The CRP-RH32-130 is a articulated industrial robot from Chengdu CRP Robot Technology, built for material handling, machine tending and palletizing on production lines. It carries a 130 kg payload to a maximum reach of 3255 mm, with a 1380 kg body and 0.06 mm repeatability. CRP builds the arm for continuous duty on a factory floor: the body is rated IP54, with an operating range of 0~45°C. It shares CRP's controller platform with the company's welding line, so the same teaching and I/O conventions apply across a mixed cell.
FEATURES
- Arm span 3.2 meters, high rigidity, strong load capacity, more stable operation
- Adopt a hollow arm structure and built-in wrist cable, without considering the interference caused by the external winding mode with the neighboring robot or peripheral equipment
- The robot body adopts highly flexible special cable
- Built-in three-phase filter can effectively improve the performance of EMC and EMI
- The body provides ID12 dual-circuit gas pipes and 26-core I0 to meet welding and handling requirements
- Using high-speed, high-overload capacity servo motor, high-precision RV reducer and the latest anti-vibration control strategy, shorten the pitch operation time, significantly shorten the cycle time
- The installation area of the whole machine is small, which can achieve high density installation and wiring, and multiple units work together
- Simple structure, friendly operation interface, easy maintenance, easy to operate
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Weight | 1380 kg |
|---|---|
| Payload | 130 kg |
| Reach | 3.25 m |
| Repeatability | ±0.06 mm |
| Materials | Cast aluminium alloy |
| Mobility | |
| Movement Type | Stationary |
| Degrees of Freedom | 6 |
| Environment | IP54, operating temperature 0~45°C |
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Weight | 1380 kg |
|---|---|
| Payload | 130 kg |
| Reach | 3.25 m |
| Repeatability | ±0.06 mm |
| Materials | Cast aluminium alloy |
| Mobility | |
| Movement Type | Stationary |
| Degrees of Freedom | 6 |
| Environment | IP54, operating temperature 0~45°C |
Images
martti
martti
martti
marttiImage Contributions
Videos
ROBOT FORUMS
Loading forums...
RATINGS
FREQUENTLY ASKED QUESTIONS
What is the CRP-RH32-130?
The CRP-RH32-130 is a articulated industrial robot from Chengdu CRP Robot Technology, built for material handling, machine tending and palletizing on production lines. It carries a 130 kg payload to a maximum reach of 3255 mm, with a 1380 kg body and 0.06 mm repeatability.
Who makes the CRP-RH32-130?
The CRP-RH32-130 is made by Chengdu CRP Robot Technology, a robotics company based in China.
How much does the CRP-RH32-130 cost?
Chengdu CRP Robot Technology has not publicly announced pricing for the CRP-RH32-130. You can enquire through RobotAIGeek for current pricing.
What is the CRP-RH32-130 used for?
The CRP-RH32-130 is designed for assembly, general-automation, machine-tending, and material-handling. It is used in automotive, electronics, warehouse & logistics, and manufacturing settings.
What is the payload capacity of the CRP-RH32-130?
The CRP-RH32-130 has a payload capacity of 130 kg and a reach of 3.25 m.
How much does the CRP-RH32-130 weigh?
The CRP-RH32-130 weighs 1,380 kg.
How many degrees of freedom does the CRP-RH32-130 have?
The CRP-RH32-130 has 6 degrees of freedom.
