DESCRIPTION
AUV Svaayatt is a Military from Planys Technologies. It is built for Mapping, Reconnaissance, Search-And-Rescue. Key figures: 110 kg, 600 min runtime.
Svaayatt is a torpedo-shaped autonomous underwater vehicle (AUV) from Planys Technologies, listed under the company's defence line. It is intended for magnetic and acoustic ranging of naval vessels, anti-submarine warfare, intelligence, surveillance and reconnaissance, mine countermeasures, search and rescue and hydrographic surveys. The vehicle weighs 110 kg and runs for up to 10 hours in ranging operations on a rechargeable 5 kWh battery, which can be upgraded. It is offered in 100 m and 300 m depth variants and has a modular, expandable payload bay. Svaayatt works in three modes: following a pre-planned path autonomously, remote control, or resting on the seabed on its adjustable-height skid frame as a resident sensor platform. Communication is by RF at the surface and USBL acoustic links underwater. Missions are planned and monitored in Planys' mission control and command software, which includes a primary flight display (PFD) interface.
FEATURES
- Torpedo-shaped AUV
- Weight 110 kg
- Endurance up to 10 hours for ranging operations
- Rechargeable 5 kWh battery (upgradeable)
- Depth variants 100 m and 300 m
- Modes: autonomous path following, remote control, seabed resident
- Skid frame for landing on the seabed, adjustable height
- Modular payload bay with expandable payload capacity
- Communication on surface and underwater: RF and USBL
- Mission control and command software suite with PFD GUI
- Applications: magnetic and acoustic ranging, anti-submarine warfare, ISR, mine countermeasures, search and rescue, hydrographic surveys
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Weight | 110 kg |
|---|---|
| Mobility | |
| Movement Type | Aquatic |
| Environment | Sea, down to 100 m or 300 m depending on variant |
| Power | |
| Battery Life | 600 min |
| Sensing & Compute | |
| Connectivity | RF (surface) and USBL (underwater) |
| Software / AI | Mission control and command software suite with PFD GUI |
ROBOT FORUMS
Loading forums...
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Weight | 110 kg |
|---|---|
| Mobility | |
| Movement Type | Aquatic |
| Environment | Sea, down to 100 m or 300 m depending on variant |
| Power | |
| Battery Life | 600 min |
| Sensing & Compute | |
| Connectivity | RF (surface) and USBL (underwater) |
| Software / AI | Mission control and command software suite with PFD GUI |
Images
martti
Image Contributions
Videos
ROBOT FORUMS
Loading forums...
RATINGS
FREQUENTLY ASKED QUESTIONS
What is the AUV Svaayatt?
Svaayatt is a torpedo-shaped autonomous underwater vehicle (AUV) from Planys Technologies, listed under the company's defence line.
Who makes the AUV Svaayatt?
The AUV Svaayatt is made by Planys Technologies, a robotics company based in India.
How much does the AUV Svaayatt cost?
Planys Technologies has not publicly announced pricing for the AUV Svaayatt. You can enquire through RobotAIGeek for current pricing.
What is the AUV Svaayatt used for?
The AUV Svaayatt is designed for mapping, reconnaissance, search-and-rescue, and surveying. It is used in defence, government, and research settings.
How much does the AUV Svaayatt weigh?
The AUV Svaayatt weighs 110 kg.
What is the battery life of the AUV Svaayatt?
The AUV Svaayatt runs for about 600 minutes on a charge.
