DESCRIPTION
The 200 t Wind-turbine Component Transfer Cart 24111A is a Trackless Transfer Cart built by Lonyu AGV, rated to carry 200 t. Lonyu designates it 24111A. It has a body measuring 8210 mm long, 3620 mm wide and 885 mm high and an unladen mass of 30 t. Mechanically, suspension is hydraulic suspension. Lonyu describes its movement as: Forward, reverse, left and right. It navigates by magnetic stripe, is commanded by automatic, positions to ±10. For power and motion, it runs on Lithium iron phosphate battery, battery life: 3 hours (full load, empty); charging is manual charging; travel speed is 48m/min (no load), 36m/min (full load). On safety, safety is handled by laser obstacle avoidance sensor + contact collision avoidance + audible and visual warning + emergency stop; braking distance is ≤500mm (full load), ≤300mm (no load); ingress protection is IP54; it climbs gradients of ≤5°. Lonyu rates it for indoor and outdoor. Lifting stroke is 200mm.
FEATURES
- Rated load: 200 t
- Unladen mass: 30 t
- Body dimensions: 8210 x 3620 x 885 mm
- Lifting stroke: 200mm
- Navigation: Magnetic stripe
- Control: Automatic
- Positioning accuracy: ±10
- Travel speed: 48m/min (no load), 36m/min (full load)
- Battery: Lithium iron phosphate battery, battery life: 3 hours (full load, empty)
- Charging: Manual charging
- Suspension: Hydraulic suspension
- Gradeability: ≤5°
- Braking distance: ≤500mm (full load), ≤300mm (no load)
- Protection rating: IP54
- Safety systems: Laser obstacle avoidance sensor + contact collision avoidance + audible and visual warning + emergency stop
- Operating environment: Indoor and outdoor
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Weight | 30000 kg |
|---|---|
| Dimensions | L 8.21 m × W 3.62 m × H 885 mm |
| Payload | 200000 kg |
| Mobility | |
| Speed | 2.88 km/h |
| Environment | Indoor and outdoor |
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Weight | 30000 kg |
|---|---|
| Dimensions | L 8.21 m × W 3.62 m × H 885 mm |
| Payload | 200000 kg |
| Mobility | |
| Speed | 2.88 km/h |
| Environment | Indoor and outdoor |
Images
Image Contributions
Videos
ROBOT FORUMS
Loading forums...
RATINGS
FREQUENTLY ASKED QUESTIONS
What is the 200 t Wind-turbine Component Transfer Cart 24111A?
The 200 t Wind-turbine Component Transfer Cart 24111A is a Trackless Transfer Cart built by Lonyu AGV, rated to carry 200 t. Lonyu designates it 24111A. It has a body measuring 8210 mm long, 3620 mm wide and 885 mm high and an unladen mass of 30 t. Mechanically, suspension is hydraulic suspension.
Who makes the 200 t Wind-turbine Component Transfer Cart 24111A?
The 200 t Wind-turbine Component Transfer Cart 24111A is made by Lonyu Agv.
How much does the 200 t Wind-turbine Component Transfer Cart 24111A cost?
Lonyu Agv has not publicly announced pricing for the 200 t Wind-turbine Component Transfer Cart 24111A. You can enquire through RobotAIGeek for current pricing.
What is the 200 t Wind-turbine Component Transfer Cart 24111A used for?
The 200 t Wind-turbine Component Transfer Cart 24111A is designed for transport.
What is the payload capacity of the 200 t Wind-turbine Component Transfer Cart 24111A?
The 200 t Wind-turbine Component Transfer Cart 24111A has a payload capacity of 200,000 kg.
How much does the 200 t Wind-turbine Component Transfer Cart 24111A weigh?
The 200 t Wind-turbine Component Transfer Cart 24111A weighs 30,000 kg.
How fast is the 200 t Wind-turbine Component Transfer Cart 24111A?
The 200 t Wind-turbine Component Transfer Cart 24111A can move at speeds of up to 2.88 km/h.
