BESCHREIBUNG
Giraffe ist ein Mobile-Robots von AIZUK Co., Ltd.. Er ist für Inspektion, Überwachung, Remote-controlled work and inspection in disaster sites and narrow hazardous spaces ausgelegt. Eckdaten: 120 min Laufzeit, 50 kg Traglast.
Giraffe is AIZUK's small electric disaster-response crawler robot for precise work in disaster zones and in narrow or dangerous places where people cannot work easily - a completely new hardware generation of the small crawler robot AIZUK has developed since fiscal 2014. Its drive changed from timing belts to chain and sprocket so it can cross sand and grass, and gaskets on every metal joint make it dust- and water-resistant: it can run outdoors in rain, ford water about 15 cm deep and be washed with a shower or pressure washer. It carries a payload of more than 50 kg on flat ground and can climb slopes and stairs over rough terrain with a 50 kg load, using sub-crawlers with 107 Nm of torque and climbing 45-degree slopes. It is remotely operated by controller over wireless or wired links - or from another room via a PC on the same network - and is controlled by a Raspberry Pi 3 Model B+ with HDMI, USB and Ethernet interfaces for adding network cameras and sensors. The basic configuration measures 1,060 x 448.7 x 382.1 mm and runs on a lithium-ion battery for 2 hours (up to 8 hours), and AIZUK customises sensors, cameras and design for each use case.
FUNKTIONEN
- Small electric disaster-response crawler with sub-crawlers (107 Nm)
- Chain-sprocket drive for sand and grass
- Dust/waterproof: runs in rain, fords ~15 cm water, washable
- Payload 50+ kg on flat ground
- slopes and stairs with 50 kg
- Climbs 45-degree slopes
- Wireless or wired remote control
- PC control from another room
- Raspberry Pi 3 Model B+ controller
- HDMI, USB 2.0/3.0, Ethernet for added cameras/sensors
- Size 1,060 x 448.7 x 382.1 mm
- Li-ion battery: 2 h (up to 8 h)
- Customised per use case
TECHNISCHE DATEN
Verifiziert| Physisch | |
| Abmessungen | L 1.06 m × W 449 mm × H 382 mm |
|---|---|
| Traglast | 50 kg |
| Mobilität | |
| Bewegungsart | Sonstige |
| Einsatzumgebung | Outdoor and indoor disaster sites, rough terrain, stairs, rain, shallow water (~15 cm) |
| Energie | |
| Akkulaufzeit | 120 min |
| Sensorik & Rechenleistung | |
| Sensoren | expandable (network cameras, sensors via USB/Ethernet) |
| Konnektivität | Wireless and wired remote control; Ethernet network |
ROBOTER-FOREN
Foren werden geladen...
TECHNISCHE DATEN
Verifiziert| Physisch | |
| Abmessungen | L 1.06 m × W 449 mm × H 382 mm |
|---|---|
| Traglast | 50 kg |
| Mobilität | |
| Bewegungsart | Sonstige |
| Einsatzumgebung | Outdoor and indoor disaster sites, rough terrain, stairs, rain, shallow water (~15 cm) |
| Energie | |
| Akkulaufzeit | 120 min |
| Sensorik & Rechenleistung | |
| Sensoren | expandable (network cameras, sensors via USB/Ethernet) |
| Konnektivität | Wireless and wired remote control; Ethernet network |
Bilder



Bildbeiträge
Videos
ROBOTER-FOREN
Foren werden geladen...
BEWERTUNGEN
HÄUFIG GESTELLTE FRAGEN
What is the Giraffe?
Giraffe is AIZUK's small electric disaster-response crawler robot for precise work in disaster zones and in narrow or dangerous places where people cannot work easily - a completely new hardware generation of the small crawler robot AIZUK has developed since fiscal 2014.
Who makes the Giraffe?
The Giraffe is made by AIZUK Co., Ltd., a robotics company based in Japan.
How much does the Giraffe cost?
AIZUK Co., Ltd. has not publicly announced pricing for the Giraffe. You can enquire through RobotAIGeek for current pricing.
What is the Giraffe used for?
The Giraffe is designed for inspektion, überwachung, and remote-controlled work and inspection in disaster sites and narrow hazardous spaces. It is used in energie, öffentliche hand, and bauwesen settings.
What is the payload capacity of the Giraffe?
The Giraffe has a payload capacity of 50 kg.
What is the battery life of the Giraffe?
The Giraffe runs for about 120 minutes on a charge.
