描述
The L4-G1 is Shenhao's explosion-proof machine for oil and gas plants — a 270 kg four-wheel differential robot sealed to IP65 and built so that nothing about it can ignite the atmosphere it works in, including the way it charges. Rather than docking metal contacts, which arc, it charges wirelessly through an explosion-proof station. It navigates tracklessly and maps the site itself during inspection with no manual teaching, then reads records and meters, recognises equipment operating status, and detects combustible and toxic gas, storing the results in structured form so a big-data expert system can support decisions and trace history. It runs six hours or more at 1 m/s across a -20 to 60°C range, with anti-collision, anti-fall and equipment self-inspection.
功能特色
- Explosion-proof design for the oil and gas industry with IP65 protection
- 1000 x 900 x 1000 mm and up to 270 kg
- Explosion-proof four-wheel differential drive at 1 m/s
- Battery life of 6 hours or more
- Explosion-proof wireless automatic charging, avoiding electric ignition and electrode wear from mechanical docking
- Trackless autonomous positioning and navigation with automatic map drawing during inspection, no manual teaching required
- Combustible and toxic gas detection
- Record reading recognition and equipment operation status recognition
- Structured storage and analysis of inspection data with big data expert system decision support
- Safety: anti-collision, anti-fall and equipment self-inspection
- Operating temperature -20 to 60 degrees Celsius
- working humidity 10% to 90% RH non-condensing
- Remote control and management of inspection data for unmanned operation
技術規格
已驗證| 物理參數 | |
| 重量 | 270 kg |
|---|---|
| 外形尺寸 | L 1 m × W 900 mm × H 1 m |
| 移動能力 | |
| 移動類型 | 帶輪的 |
| 速度 | 3.6 km/h |
| 作業環境 | Oil and gas plants and explosive atmospheres; IP65; -20 to 60 degrees Celsius; 10-90% RH non-condensing |
| 致動器 | Explosion-proof four-wheel differential wheeled chassis with wireless automatic charging |
| 電源與續航 | |
| 續航時間 | ≥6 h |
| 感知與計算 | |
| 感測器 | visible light camera, infrared thermal imager, combustible and toxic gas detectors |
| 軟體 / AI | Trackless autonomous positioning and navigation with self-drawn maps; structured inspection data storage with big-data expert analysis |
技術規格
已驗證| 物理參數 | |
| 重量 | 270 kg |
|---|---|
| 外形尺寸 | L 1 m × W 900 mm × H 1 m |
| 移動能力 | |
| 移動類型 | 帶輪的 |
| 速度 | 3.6 km/h |
| 作業環境 | Oil and gas plants and explosive atmospheres; IP65; -20 to 60 degrees Celsius; 10-90% RH non-condensing |
| 致動器 | Explosion-proof four-wheel differential wheeled chassis with wireless automatic charging |
| 電源與續航 | |
| 續航時間 | ≥6 h |
| 感知與計算 | |
| 感測器 | visible light camera, infrared thermal imager, combustible and toxic gas detectors |
| 軟體 / AI | Trackless autonomous positioning and navigation with self-drawn maps; structured inspection data storage with big-data expert analysis |
圖片
martti
圖片貢獻
影片
機器人論壇
正在載入論壇...
評分
常見問題
What is the Shenhao L4-G1 Explosion-Proof Wheeled Inspection Robot?
The L4-G1 is Shenhao's explosion-proof machine for oil and gas plants — a 270 kg four-wheel differential robot sealed to IP65 and built so that nothing about it can ignite the atmosphere it works in, including the way it charges.
Who makes the Shenhao L4-G1 Explosion-Proof Wheeled Inspection Robot?
The Shenhao L4-G1 Explosion-Proof Wheeled Inspection Robot is made by Shenhao Technology, a robotics company based in China.
How much does the Shenhao L4-G1 Explosion-Proof Wheeled Inspection Robot cost?
Shenhao Technology has not publicly announced pricing for the Shenhao L4-G1 Explosion-Proof Wheeled Inspection Robot. You can enquire through RobotAIGeek for current pricing.
What is the Shenhao L4-G1 Explosion-Proof Wheeled Inspection Robot used for?
The Shenhao L4-G1 Explosion-Proof Wheeled Inspection Robot is designed for 檢查, 監測, oil and gas plant inspection, and petrochemical site monitoring. It is used in 能源, 製造業, and 安全 settings.
How much does the Shenhao L4-G1 Explosion-Proof Wheeled Inspection Robot weigh?
The Shenhao L4-G1 Explosion-Proof Wheeled Inspection Robot weighs 270 kg.
How fast is the Shenhao L4-G1 Explosion-Proof Wheeled Inspection Robot?
The Shenhao L4-G1 Explosion-Proof Wheeled Inspection Robot can move at speeds of up to 3.6 km/h.
What is the battery life of the Shenhao L4-G1 Explosion-Proof Wheeled Inspection Robot?
The Shenhao L4-G1 Explosion-Proof Wheeled Inspection Robot runs for ≥6 h on a charge.
