描述
GPM-R20H是Huizhou Gurki Intelligent Equipment Co., Ltd的Warehouse-Robots。 面向內部物流、物料搬運、包裝設計。 關鍵數據：520 kg、負載 20 kg、臂展 1700 mm。
The Gurki GPM-R20H is a 20 kg-payload collaborative end-of-line palletizing workstation for cartons and other packaged goods. It combines a robot arm, lifting column, controls, pneumatics, and palletizing base in an integrated system.
功能特色
- Touchscreen operation
- integrated robot, power, pneumatics, and lifting column
- manual or automatic pallet supply
- suction-cup or clamp gripper
- standalone use or integration with pallet feeders and conveyors. OEM specifications for GPM-R20H: 8–10 boxes per minute
- 20 kg load
- 1700 mm working radius
- 520 kg equipment weight
- palletizing height 300–2200 mm
- machine height 2250–2800 mm
- 3000 W at 220 V / 50 Hz
- protection rating not published
- compatible product size L200–600 × W200–600 × H100–600 mm. OEM states deployment within three hours and a footprint below 1 m²
- the ambiguous '1000×1200×140 mm covered area' row was not mapped to typed dimensions.
技術規格
| 物理參數 | |
| 重量 | 520 kg |
|---|---|
| 負載 | 20 kg |
| 臂展 | 1.7 m |
| 移動能力 | |
| 移動類型 | 文具 |
| 操作能力 | 中 |
| 電源與續航 | |
| 續航時間 | 3 hours |
技術規格
| 物理參數 | |
| 重量 | 520 kg |
|---|---|
| 負載 | 20 kg |
| 臂展 | 1.7 m |
| 移動能力 | |
| 移動類型 | 文具 |
| 操作能力 | 中 |
| 電源與續航 | |
| 續航時間 | 3 hours |
圖片
martti
圖片貢獻
機器人論壇
正在載入論壇...
評分
常見問題
What is the GPM-R20H?
The Gurki GPM-R20H is a 20 kg-payload collaborative end-of-line palletizing workstation for cartons and other packaged goods. It combines a robot arm, lifting column, controls, pneumatics, and palletizing base in an integrated system.
Who makes the GPM-R20H?
The GPM-R20H is made by Huizhou Gurki Intelligent Equipment Co., Ltd, a robotics company based in China.
How much does the GPM-R20H cost?
Huizhou Gurki Intelligent Equipment Co., Ltd has not publicly announced pricing for the GPM-R20H. You can enquire through RobotAIGeek for current pricing.
What is the GPM-R20H used for?
The GPM-R20H is designed for 內部物流, 物料搬運, 包裝, and 托盤化. It is used in 製造業 settings.
What is the payload capacity of the GPM-R20H?
The GPM-R20H has a payload capacity of 20 kg and a reach of 1.7 m.
How much does the GPM-R20H weigh?
The GPM-R20H weighs 520 kg.
What is the battery life of the GPM-R20H?
The GPM-R20H runs for 3 hours on a charge.
