DINERBOT T5

Delivery-RobotsChinaChina已停產
DINERBOT T5
比較
行業:
價格:
尚未公布
發布年份:
2020

描述

DINERBOT T5是Keenon Robotics的Delivery-Robots。 面向餐盤系列、送貨設計。 關鍵數據:58 kg、續航 900 分鐘、負載 40 kg、2020 年發布。

The Keenon T5 was a commercial food-delivery robot, marketed as the "delivery master" of the company's early restaurant line and built around a four-layer tray stack carrying 10 kg per layer, with adjustable spacing to take plates of differing heights. It navigated on Keenon's own SLAM system - simultaneous localisation and mapping fusing wheel encoders, a gyroscope, LiDAR and odometry - which the company positioned as the basis for running stably and efficiently through a working restaurant. Obstacle avoidance layered depth vision, stereo RGBD vision, LiDAR, a collision sensor and infrared ranging on top of that, and an Android control system with a touch sensor handled interaction. Multiple T5s coordinated through a communication system Keenon developed in-house, scheduling deliveries between machines so they could work the same floor without conflict. A regional speed-limit function let the robot slow itself according to the slope of the ground it was crossing. It also carried an expression display and voice interaction for communicating with diners. The T5 is discontinued; Keenon's current delivery line is the DINERBOT T-series.

功能特色

  • Four-layer tray stack carrying 10 kg per layer.
  • Adjustable tray spacing - top tray 188 mm, remaining trays 176 mm - for differing plate heights.
  • Keenon's own SLAM localisation and mapping using encoders, gyroscope, LiDAR and odometry.
  • Obstacle avoidance via depth vision, stereo RGBD, LiDAR, collision sensor and infrared ranging.
  • Android control system with touch sensor for interaction.
  • Multi-robot coordination through an in-house communication system for AI delivery scheduling.
  • Regional speed limiting that adapts to floor slope.
  • Expression display and voice interaction for communicating with diners.
  • 500 x 500 x 1200 mm
  • 58 kg.
  • DC 48 V 12 Ah battery
  • 15 hours running, over 48 hours standby, 4 hour charge.
  • 50 W rated power
  • standby current below 0.3 A.

技術規格

物理參數
重量58 kg
外形尺寸L 500 mm × W 500 mm × H 1.2 m
負載40 kg
移動能力
移動類型帶輪的
速度3.6 km/h
作業環境Indoor: restaurants, hotel buffets, golf club restaurants, offices and factories; passages of 80 cm or more
電源與續航
續航時間15 hours
充電類型Charger, AC 100-240 V 50/60 Hz
充電時間4 hours
感知與計算
感測器LiDAR, 3D camera, Bumper
來源:製造商官網來源:第三方暫無來源來源狀態基於該機器人已登記的資料來源。

機器人論壇

正在載入論壇...

常見問題

What is the DINERBOT T5?

The Keenon T5 was a commercial food-delivery robot, marketed as the "delivery master" of the company's early restaurant line and built around a four-layer tray stack carrying 10 kg per layer, with adjustable spacing to take plates of differing heights.

Who makes the DINERBOT T5?

The DINERBOT T5 is made by Keenon Robotics, a robotics company based in China.

How much does the DINERBOT T5 cost?

Keenon Robotics has not publicly announced pricing for the DINERBOT T5. You can enquire through RobotAIGeek for current pricing.

What is the DINERBOT T5 used for?

The DINERBOT T5 is designed for 餐盤系列 and 送貨. It is used in 飯店 and 餐廳 settings.

What is the payload capacity of the DINERBOT T5?

The DINERBOT T5 has a payload capacity of 40 kg.

How much does the DINERBOT T5 weigh?

The DINERBOT T5 weighs 58 kg.

How fast is the DINERBOT T5?

The DINERBOT T5 can move at speeds of up to 3.6 km/h.

What is the battery life of the DINERBOT T5?

The DINERBOT T5 runs for 15 hours on a charge. It takes 4 hours to charge.
