描述
The SF25-C1900 is a 25 kg stamping press robot in CHAIFU's PRESS series, a vertical articulated industrial robot with 4 axes and a maximum reach of 1900 mm. Repeatability is ±0.08mm and it is driven by ac servo motors, with IP 65 (The wrist is protected to IP 67) protection. PRESS robots use LIKEHEATTREATMENT thermal technology for a solid foundation on every press stroke, covering 8 kg to 25 kg loads; base axes are IP65 and wrist axes IP67. CHAIFU builds the PRESS series in Shanghai with its own LIKEPRECISION RV precision gearboxes and servo motors, and positions it for stamping lines, precise handling and palletising.
功能特点
- PRESS series stamping press robot
- Payload 25 kg
- Maximum reach 1900 mm
- 4 axes, vertical articulated
- Repeatability ±0.08mm
- Drive: AC Servo Motor
- Protection IP 65 (The wrist is protected to IP 67)
- LIKEPRECISION RV precision gearbox and CHAIFU servo motors
技术规格
已验证| 物理参数 | |
| 负载 | 25 kg |
|---|---|
| 臂展 | 1.9 m |
| 移动能力 | |
| 运动类型 | 文具 |
| 自由度 | 4 |
| 操作能力 | 高 |
| 作业环境 | Industrial production environments; IP 65 (The wrist is protected to IP 67). |
| 执行器 | AC Servo Motor drive with LIKEPRECISION RV precision gearboxes |
技术规格
已验证| 物理参数 | |
| 负载 | 25 kg |
|---|---|
| 臂展 | 1.9 m |
| 移动能力 | |
| 运动类型 | 文具 |
| 自由度 | 4 |
| 操作能力 | 高 |
| 作业环境 | Industrial production environments; IP 65 (The wrist is protected to IP 67). |
| 执行器 | AC Servo Motor drive with LIKEPRECISION RV precision gearboxes |
图片贡献
视频
机器人论坛
正在加载论坛...
评分
常见问题
What is the CHAIFU SF25-C1900?
The SF25-C1900 is a 25 kg stamping press robot in CHAIFU's PRESS series, a vertical articulated industrial robot with 4 axes and a maximum reach of 1900 mm. Repeatability is ±0.08mm and it is driven by ac servo motors, with IP 65 (The wrist is protected to IP 67) protection.
Who makes the CHAIFU SF25-C1900?
The CHAIFU SF25-C1900 is made by Chaifu Robot, a robotics company based in China.
How much does the CHAIFU SF25-C1900 cost?
Chaifu Robot has not publicly announced pricing for the CHAIFU SF25-C1900. You can enquire through RobotAIGeek for current pricing.
What is the CHAIFU SF25-C1900 used for?
The CHAIFU SF25-C1900 is designed for 机床操作 and 物料搬运. It is used in 汽车 and 制造业 settings.
What is the payload capacity of the CHAIFU SF25-C1900?
The CHAIFU SF25-C1900 has a payload capacity of 25 kg and a reach of 1.9 m.
How many degrees of freedom does the CHAIFU SF25-C1900 have?
The CHAIFU SF25-C1900 has 4 degrees of freedom.
