DESCRIPTION
Vision 60 is a Mobile-Robots from Ghost Robotics. It is built for Research, Security, Inspection. Key figures: 51 kg, 189 min runtime, 10 kg payload.
Vision 60 is Ghost Robotics' flagship Quadrupedal Unmanned Ground Vehicle (Q-UGV) for defense, public safety, and commercial inspection. It is an all-electric, IP67 modular platform with field-replaceable legs and open payload architecture for sensors, CBRN, manipulators, and radios.
FEATURES
- Q-UGV quadruped: IP67
- operating temp −40°C to 55°C (OEM /vision-60 specs). Endurance ~3.15 h continuous walking at 0.9 m/s / ~10 km, or ~21 h standby
- ~3 h standard charge (OEM specs). Speed: standard walk 0.9 m/s
- fast-walk up to 1.2 m/s
- sprint ~2.4 m/s (OEM specs
- marketing also cites up to 2.5 m/s). Payload 10 kg (22 lb) with payload-compensation mode (OEM). Key dims: L950 × W570 × H685 mm standing
- ride height 419 mm
- tare 51 kg (OEM). Compute NVIDIA Xavier 32 GB
- 5× RGB + 4× RealSense D435
- dual-antenna RTK GPS (OEM). Comms: integrated 2.4/5.8 GHz Wi-Fi & 4G/LTE
- GigE for external radios (OEM). Autonomy: perception-aided mobility, record-playback, Mission Control GPS/GPS-denied modes (OEM). Export EAR-99 / industrial robots HS (OEM).
TECHNICAL SPECIFICATIONS
| Physical | |
| Weight | 51 kg |
|---|---|
| Dimensions | L 950 mm × W 570 mm × H 685 mm |
| Payload | 10 kg |
| Mobility | |
| Movement Type | Quadruped |
| Power | |
| Battery Life | 189 min |
Videos
Tough Stump Vision 60 Capabilities from Ghost Robotics
Ghost Robotics
ONYX NAUT & SENTRY - Ghost Robotics V60 robotic dog
Ghost Robotics
MILITARY TECH: Ghost Robotics VISION 60 Q-UGV Ground Robot
Ghost Robotics
ROBOT FORUMS
Loading forums...
TECHNICAL SPECIFICATIONS
| Physical | |
| Weight | 51 kg |
|---|---|
| Dimensions | L 950 mm × W 570 mm × H 685 mm |
| Payload | 10 kg |
| Mobility | |
| Movement Type | Quadruped |
| Power | |
| Battery Life | 189 min |
Images
Videos
Tough Stump Vision 60 Capabilities from Ghost Robotics
Ghost Robotics
ONYX NAUT & SENTRY - Ghost Robotics V60 robotic dog
Ghost Robotics
MILITARY TECH: Ghost Robotics VISION 60 Q-UGV Ground Robot
Ghost Robotics
Vision 60 Video 2390
Ghost Robotics
ROBOT FORUMS
Loading forums...
RATINGS
FREQUENTLY ASKED QUESTIONS
What is the Vision 60?
Vision 60 is Ghost Robotics' flagship Quadrupedal Unmanned Ground Vehicle (Q-UGV) for defense, public safety, and commercial inspection. It is an all-electric, IP67 modular platform with field-replaceable legs and open payload architecture for sensors, CBRN, manipulators, and radios.
Who makes the Vision 60?
The Vision 60 is made by Ghost Robotics, a robotics company based in United States.
How much does the Vision 60 cost?
Ghost Robotics has not publicly announced pricing for the Vision 60. You can enquire through RobotAIGeek for current pricing.
What is the Vision 60 used for?
The Vision 60 is designed for research, security, and inspection. It is used in research, manufacturing, and security & patrol settings.
What is the payload capacity of the Vision 60?
The Vision 60 has a payload capacity of 10 kg.
How much does the Vision 60 weigh?
The Vision 60 weighs 51 kg.
What is the battery life of the Vision 60?
The Vision 60 runs for about 189 minutes on a charge.
