DESCRIPTION
Peitian AIR3-560-XP is an Industrial-Robot from Peitian Robot. It is built for Assembly, Pick-and-place, Loading and unloading. Key figures: 38 kg, 3 kg payload, 560 mm reach, 6 degrees of freedom.
The AIR3-560-XP is a desktop-class six-axis articulated arm from Peitian's AIR range, carrying 3 kg to a reach of 560 mm. Peitian quotes position repeatability of ±0.03mm, which is the figure that decides whether an arm of this size can be trusted on close-tolerance work rather than only on gross handling. The manipulator weighs 38 kg. and can be mounted Floor or wall or ceiling. It runs on Peitian's inCube20 / ARC5-12 controller cabinet.
FEATURES
- Six-axis articulated industrial robot arm
- Rated payload 3 kg
- Maximum reach 560 mm
- Manipulator weight 38 kg
- Position repeatability ±0.03mm
- Mounting: Floor / wall / ceiling
- Compatible controller cabinets: inCube20 / ARC5-12
- Working range Axis 1 rotation -170°/+170°
- Axis 2 arm -110°/+120°
- Axis 3 arm -108°/+152°
- Axis 4 wrist -200°/+200°
- Axis 5 bend -118°/+118°
- Axis 6 turn -350°/+350°
- Rotation rate Axis 1 rotation 450°/s
- Axis 2 arm 450°/s
- Axis 3 arm 525°/s
- Axis 4 wrist 600°/s
- Axis 5 bend 600°/s
- Axis 6 turn 800°/s
- Ambient temperature 0 to 45 degrees Celsius, humidity up to 95% non-condensing, altitude up to 1000 m
- No corrosive, flammable or explosive gases permitted in the operating environment
TECHNICAL SPECIFICATIONS
| Physical | |
| Weight | 38 kg |
|---|---|
| Payload | 3 kg |
| Reach | 560 mm |
| Mobility | |
| Movement Type | Stationary |
| Degrees of Freedom | 6 |
| Manipulation | High |
| Environment | Industrial indoor use, 0 to 45 degrees Celsius, humidity up to 95% non-condensing, altitude up to 1000 m; no corrosive, flammable or explosive gases |
| Actuators | 6-axis six-axis articulated manipulator, mounted Floor or wall or ceiling |
| Sensing & Compute | |
| Software / AI | Driven by Peitian inCube20 / ARC5-12 controller cabinets |
ROBOT FORUMS
Loading forums...
TECHNICAL SPECIFICATIONS
| Physical | |
| Weight | 38 kg |
|---|---|
| Payload | 3 kg |
| Reach | 560 mm |
| Mobility | |
| Movement Type | Stationary |
| Degrees of Freedom | 6 |
| Manipulation | High |
| Environment | Industrial indoor use, 0 to 45 degrees Celsius, humidity up to 95% non-condensing, altitude up to 1000 m; no corrosive, flammable or explosive gases |
| Actuators | 6-axis six-axis articulated manipulator, mounted Floor or wall or ceiling |
| Sensing & Compute | |
| Software / AI | Driven by Peitian inCube20 / ARC5-12 controller cabinets |
Images
martti
Image Contributions
Videos
ROBOT FORUMS
Loading forums...
RATINGS
FREQUENTLY ASKED QUESTIONS
What is the Peitian AIR3-560-XP?
The AIR3-560-XP is a desktop-class six-axis articulated arm from Peitian's AIR range, carrying 3 kg to a reach of 560 mm. Peitian quotes position repeatability of ±0.03mm, which is the figure that decides whether an arm of this size can be trusted on close-tolerance work rather than only on gross handling.
Who makes the Peitian AIR3-560-XP?
The Peitian AIR3-560-XP is made by Peitian Robot, a robotics company based in China.
How much does the Peitian AIR3-560-XP cost?
Peitian Robot has not publicly announced pricing for the Peitian AIR3-560-XP. You can enquire through RobotAIGeek for current pricing.
What is the Peitian AIR3-560-XP used for?
The Peitian AIR3-560-XP is designed for assembly, pick-and-place, loading and unloading, and handling. It is used in research and manufacturing settings.
What is the payload capacity of the Peitian AIR3-560-XP?
The Peitian AIR3-560-XP has a payload capacity of 3 kg and a reach of 560 mm.
How much does the Peitian AIR3-560-XP weigh?
The Peitian AIR3-560-XP weighs 38 kg.
How many degrees of freedom does the Peitian AIR3-560-XP have?
The Peitian AIR3-560-XP has 6 degrees of freedom.
