Peitian AIR20-3100

Peitian Robot

Industrial-Robot China

ChinaReleased

★Not rated yet

Compare

Sources:

cdn.robotaigeek.com

Industries:

Research Manufacturing

Uses:

Assembly Pick-and-placeLoading and unloadinghandlingpalletisinginjection mouldingweldinggrinding and polishingdispensingpacking

Price:

Not announced

DESCRIPTION

Peitian AIR20-3100 is an Industrial-Robot from Peitian Robot. It is built for Assembly, Pick-and-place, Loading and unloading. Key figures: 550 kg, 20 kg payload, 3097 mm reach, 6 degrees of freedom.

The AIR20-3100 is a medium-payload six-axis articulated arm from Peitian's AIR range, carrying 20 kg to a reach of 3097 mm. Peitian quotes position repeatability of ±0.03mm, which is the figure that decides whether an arm of this size can be trusted on close-tolerance work rather than only on gross handling. The manipulator weighs 550 kg. It is sealed to IP54(Wrist: IP67), and can be mounted Floor or ceiling. It runs on Peitian's ARC5-280 controller cabinet.

FEATURES

Six-axis articulated industrial robot arm
Rated payload 20 kg
Maximum reach 3097 mm
Manipulator weight 550 kg
Position repeatability ±0.03mm
Ingress protection IP54(Wrist: IP67)
Mounting: Floor / ceiling
Compatible controller cabinets: ARC5-280
Working range Axis 1 rotation -170°/+170°
Axis 2 arm -100°/+100°
Axis 3 arm -110°/+165°
Axis 4 wrist -350°/+350°
Axis 5 bend -125°/+125°
Axis 6 turn -360°/+360°
Rotation rate Axis 1 rotation 185°/s
Axis 2 arm 180°/s
Axis 3 arm 180°/s
Axis 4 wrist 310°/s
Axis 5 bend 375°/s
Axis 6 turn 470°/s
Ambient temperature 0 to 45 degrees Celsius, humidity up to 95% non-condensing, altitude up to 1000 m
No corrosive, flammable or explosive gases permitted in the operating environment

TECHNICAL SPECIFICATIONS

Physical
Weight	550 kg
Payload	20 kg
Reach	3.1 m
Mobility
Movement Type	Stationary
Degrees of Freedom	6
Manipulation	High
Environment	Industrial indoor use, 0 to 45 degrees Celsius, humidity up to 95% non-condensing, altitude up to 1000 m; no corrosive, flammable or explosive gases
Actuators	6-axis six-axis articulated manipulator, mounted Floor or ceiling
Sensing & Compute
Software / AI	Driven by Peitian ARC5-280 controller cabinets

Manufacturer-sourcedThird-party sourcedUnsourcedSource status is based on this robot's listed sources.

ROBOT FORUMS

Loading forums...

TECHNICAL SPECIFICATIONS

Physical
Weight	550 kg
Payload	20 kg
Reach	3.1 m
Mobility
Movement Type	Stationary
Degrees of Freedom	6
Manipulation	High
Environment	Industrial indoor use, 0 to 45 degrees Celsius, humidity up to 95% non-condensing, altitude up to 1000 m; no corrosive, flammable or explosive gases
Actuators	6-axis six-axis articulated manipulator, mounted Floor or ceiling
Sensing & Compute
Software / AI	Driven by Peitian ARC5-280 controller cabinets

Manufacturer-sourcedThird-party sourcedUnsourcedSource status is based on this robot's listed sources.

FREQUENTLY ASKED QUESTIONS

What is the Peitian AIR20-3100?

Who makes the Peitian AIR20-3100?

The Peitian AIR20-3100 is made by Peitian Robot, a robotics company based in China.

How much does the Peitian AIR20-3100 cost?

Peitian Robot has not publicly announced pricing for the Peitian AIR20-3100. You can enquire through RobotAIGeek for current pricing.

What is the Peitian AIR20-3100 used for?

The Peitian AIR20-3100 is designed for assembly, pick-and-place, loading and unloading, and handling. It is used in research and manufacturing settings.
