Peitian AIR20-2000

Peitian Robot

Industrial-Robot China

ChinaReleased

★Not rated yet

Compare

Sources:

cdn.robotaigeek.com

Industries:

Research Manufacturing

Uses:

Assembly Pick-and-placeLoading and unloadinghandlingpalletisinginjection mouldingweldinggrinding and polishingdispensingpacking

Price:

Not announced

DESCRIPTION

Peitian AIR20-2000 is an Industrial-Robot from Peitian Robot. It is built for Assembly, Pick-and-place, Loading and unloading. Key figures: 280 kg, 20 kg payload, 2001 mm reach, 6 degrees of freedom.

The AIR20-2000 is a medium-payload six-axis articulated arm from Peitian's AIR range, carrying 20 kg to a reach of 2001 mm. Peitian quotes position repeatability of ±0.03mm, which is the figure that decides whether an arm of this size can be trusted on close-tolerance work rather than only on gross handling. The manipulator weighs 280 kg. It is sealed to IP54(Wrist: IP67), and can be mounted Floor or wall or ceiling. It runs on Peitian's inCube22 / ARC5-25 controller cabinet.

FEATURES

Six-axis articulated industrial robot arm
Rated payload 20 kg
Maximum reach 2001 mm
Manipulator weight 280 kg
Position repeatability ±0.03mm
Ingress protection IP54(Wrist: IP67)
Mounting: Floor / wall / ceiling
Compatible controller cabinets: inCube22 / ARC5-25
Working range Axis 1 rotation -170°/+170°
Axis 2 arm -95°/+155°
Axis 3 arm -95°/+170°
Axis 4 wrist -185°/+185°
Axis 5 bend -135°/+135°
Axis 6 turn -400°/+400°
Rotation rate Axis 1 rotation 220°/s
Axis 2 arm 220°/s
Axis 3 arm 170°/s
Axis 4 wrist 375°/s
Axis 5 bend 465°/s
Axis 6 turn 755°/s
Ambient temperature 0 to 45 degrees Celsius, humidity up to 95% non-condensing, altitude up to 1000 m
No corrosive, flammable or explosive gases permitted in the operating environment

TECHNICAL SPECIFICATIONS

Physical
Weight	280 kg
Payload	20 kg
Reach	2 m
Mobility
Movement Type	Stationary
Degrees of Freedom	6
Manipulation	High
Environment	Industrial indoor use, 0 to 45 degrees Celsius, humidity up to 95% non-condensing, altitude up to 1000 m; no corrosive, flammable or explosive gases
Actuators	6-axis six-axis articulated manipulator, mounted Floor or wall or ceiling
Sensing & Compute
Software / AI	Driven by Peitian inCube22 / ARC5-25 controller cabinets

Manufacturer-sourcedThird-party sourcedUnsourcedSource status is based on this robot's listed sources.

ROBOT FORUMS

Loading forums...

TECHNICAL SPECIFICATIONS

Physical
Weight	280 kg
Payload	20 kg
Reach	2 m
Mobility
Movement Type	Stationary
Degrees of Freedom	6
Manipulation	High
Environment	Industrial indoor use, 0 to 45 degrees Celsius, humidity up to 95% non-condensing, altitude up to 1000 m; no corrosive, flammable or explosive gases
Actuators	6-axis six-axis articulated manipulator, mounted Floor or wall or ceiling
Sensing & Compute
Software / AI	Driven by Peitian inCube22 / ARC5-25 controller cabinets

Manufacturer-sourcedThird-party sourcedUnsourcedSource status is based on this robot's listed sources.

FREQUENTLY ASKED QUESTIONS

What is the Peitian AIR20-2000?

Who makes the Peitian AIR20-2000?

The Peitian AIR20-2000 is made by Peitian Robot, a robotics company based in China.

How much does the Peitian AIR20-2000 cost?

Peitian Robot has not publicly announced pricing for the Peitian AIR20-2000. You can enquire through RobotAIGeek for current pricing.

What is the Peitian AIR20-2000 used for?

The Peitian AIR20-2000 is designed for assembly, pick-and-place, loading and unloading, and handling. It is used in research and manufacturing settings.
