Peitian AIR12-2000-HW

Peitian Robot

Industrial-Robot China

ChinaReleased

★Not rated yet

Compare

Sources:

cdn.robotaigeek.com

Industries:

Research Manufacturing

Uses:

Assembly Pick-and-placeLoading and unloadinghandlingpalletisinginjection mouldingweldinggrinding and polishingdispensingpacking

Price:

Not announced

DESCRIPTION

Peitian AIR12-2000-HW is an Industrial-Robot from Peitian Robot. It is built for Assembly, Pick-and-place, Loading and unloading. Key figures: 271 kg, 12 kg payload, 2004.6 mm reach, 6 degrees of freedom.

The AIR12-2000-HW is a small-payload six-axis articulated arm from Peitian's AIR range, carrying 12 kg to a reach of 2004.6 mm. Peitian quotes position repeatability of ±0.06mm, which is the figure that decides whether an arm of this size can be trusted on close-tolerance work rather than only on gross handling. The manipulator weighs 271 kg. It is sealed to IP54(Wrist: IP67), and can be mounted Floor or wall or ceiling. It runs on Peitian's inCube22 / ARC5-25 controller cabinet. This is a hollow-wrist model: dress packs and services run through the wrist rather than around it, which stops cables snagging and wearing in applications where the tool rotates continuously.

FEATURES

Hollow-wrist six-axis industrial robot arm
Rated payload 12 kg
Maximum reach 2004.6 mm
Manipulator weight 271 kg
Position repeatability ±0.06mm
Ingress protection IP54(Wrist: IP67)
Mounting: Floor / wall / ceiling
Compatible controller cabinets: inCube22 / ARC5-25
Working range Axis 1 rotation -170°/+170°
Axis 2 arm -95°/+150°
Axis 3 arm -115°/+166°
Axis 4 wrist -155°/+155°
Axis 5 bend -120°/+120°
Axis 6 turn -360°/+360°
Rotation rate Axis 1 rotation 220°/s
Axis 2 arm 220°/s
Axis 3 arm 220°/s
Axis 4 wrist 430°/s
Axis 5 bend 450°/s
Axis 6 turn 720°/s
Ambient temperature 0 to 45 degrees Celsius, humidity up to 95% non-condensing, altitude up to 1000 m
No corrosive, flammable or explosive gases permitted in the operating environment

TECHNICAL SPECIFICATIONS

Physical
Weight	271 kg
Payload	12 kg
Reach	2 m
Mobility
Movement Type	Stationary
Degrees of Freedom	6
Manipulation	High
Environment	Industrial indoor use, 0 to 45 degrees Celsius, humidity up to 95% non-condensing, altitude up to 1000 m; no corrosive, flammable or explosive gases
Actuators	6-axis hollow-wrist six-axis manipulator, mounted Floor or wall or ceiling
Sensing & Compute
Software / AI	Driven by Peitian inCube22 / ARC5-25 controller cabinets

Manufacturer-sourcedThird-party sourcedUnsourcedSource status is based on this robot's listed sources.

ROBOT FORUMS

Loading forums...

TECHNICAL SPECIFICATIONS

Physical
Weight	271 kg
Payload	12 kg
Reach	2 m
Mobility
Movement Type	Stationary
Degrees of Freedom	6
Manipulation	High
Environment	Industrial indoor use, 0 to 45 degrees Celsius, humidity up to 95% non-condensing, altitude up to 1000 m; no corrosive, flammable or explosive gases
Actuators	6-axis hollow-wrist six-axis manipulator, mounted Floor or wall or ceiling
Sensing & Compute
Software / AI	Driven by Peitian inCube22 / ARC5-25 controller cabinets

Manufacturer-sourcedThird-party sourcedUnsourcedSource status is based on this robot's listed sources.

FREQUENTLY ASKED QUESTIONS

What is the Peitian AIR12-2000-HW?

Who makes the Peitian AIR12-2000-HW?

The Peitian AIR12-2000-HW is made by Peitian Robot, a robotics company based in China.

How much does the Peitian AIR12-2000-HW cost?

Peitian Robot has not publicly announced pricing for the Peitian AIR12-2000-HW. You can enquire through RobotAIGeek for current pricing.

What is the Peitian AIR12-2000-HW used for?

The Peitian AIR12-2000-HW is designed for assembly, pick-and-place, loading and unloading, and handling. It is used in research and manufacturing settings.
