DESCRIPTION
MOVA LiDAX Ultra AWD is an Agricultural-Robots from MOVA. It is built for Agriculture, Mapping, Navigation. Key figures: 23.6 kg, 170 min runtime, price $1,799–$2,199.
All-wheel-drive robotic lawn mower series from MOVA for larger and sloped residential lawns, offered in variants rated for 1000, 1600 and 2000 m² per map (US: 2000 AWD at 0.5 acre and 3000 AWD at 0.75 acre). All variants share the same 740 × 532 × 321 mm, 23.6 kg body and battery. Cutting uses two floating discs with six blades each, driven by dual 180 W motors, for a 40 cm cutting width; height is set electronically from 3 to 10 cm. The 36 V, 7.5 Ah (243 Wh) battery is rated for 150-170 minutes and 800-1000 m² per charge, with U-shaped path planning and automatic resume after recharging. UltraTrim 2.0 extends the discs outward to cut within 3 cm of edges. UltraView 3.0 navigation fuses a 360° 3D LiDAR with a 70 m range and dual 1080p cameras, so no boundary wire or RTK station is required; MOVA says it keeps positioning under dense foliage and in weak GPS conditions. Four 116 W hub motors with independent suspension and omni wheels are rated for 80% slopes and 6 cm obstacles. AI vision plus a bumper handle obstacle avoidance across 300+ object types. The mower charges at 5 A, reaching 95% from 15% in 65 minutes, and is controlled through the MOVAhome App with two maps, up to 150 zones and seasonal schedules. Built-in 4G and GPS tracking come with three years of free service, alongside an off-map alarm, AirTag slot and TrueGuard live-video patrol. MOVA lists 66 dB in standard mode, IPX6 protection and a three-year warranty.
FEATURES
- UltraView 3.0 combines a 360° 3D LiDAR (70 m range) with dual 1080p RGB cameras for wire-free, RTK-free mapping
- AI-assisted auto-mapping separates grass from non-grass areas and generates a 3D map with virtual boundaries
- All-wheel drive with four 116 W hub motors rated for slopes up to 80% (38.6°)
- Independent suspension allows crossing vertical obstacles up to 6 cm
- Omni wheels give a near-zero turning radius
- Two floating cutting discs with 6 blades each and dual 180 W motors give a 40 cm cutting width
- Cutting height 3-10 cm, adjusted electronically from the app
- UltraTrim 2.0 extends the discs outward to cut within 3 cm of lawn edges
- 36 V, 7.5 Ah (243 Wh) battery: 150-170 min runtime and 800-1000 m² per charge
- Charges at 5 A
- 65 min from 15% to 95%
- Variants rated for 1000, 1600 or 2000 m² per map (US: 0.5 and 0.75 acre), with a second map supported
- AI obstacle recognition of 300+ object types, down to 2 x 2 cm
- Up to 150 zones with no-go zones, navigation channels and per-zone settings in the MOVAhome App
- Built-in 4G and GPS tracking with 3 years of free service, off-map alarm with PIN and AirTag slot
- TrueGuard: live video, human detection with photo alerts, auto patrol and live audio
- Noise stated at 66 dB in standard cutting mode
- IPX6
- 3-year warranty
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Weight | 23.6 kg |
|---|---|
| Dimensions | L 740 mm × W 532 mm × H 321 mm |
| Mobility | |
| Movement Type | Wheeled |
| Environment | Residential lawns outdoors, wire-free; returns to its charging station, IPX6 |
| Power | |
| Battery Life | 170 min |
| Sensing & Compute | |
| Sensors | 360° 3D LiDAR (70 m range, IP6K6-rated), dual 1080p RGB cameras (120° wide-angle, 2 MP 3D imaging), bumper, built-in GPS (location tracking), weather/rain sensing, lift detection |
| Connectivity | MOVAhome App; built-in 4G with 3-year free service; GPS location tracking; AirTag compatible |
| Software / AI | UltraView 3.0: 360° 3D LiDAR + AI dual vision; RTK-free, no boundary wire |
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Weight | 23.6 kg |
|---|---|
| Dimensions | L 740 mm × W 532 mm × H 321 mm |
| Mobility | |
| Movement Type | Wheeled |
| Environment | Residential lawns outdoors, wire-free; returns to its charging station, IPX6 |
| Power | |
| Battery Life | 170 min |
| Sensing & Compute | |
| Sensors | 360° 3D LiDAR (70 m range, IP6K6-rated), dual 1080p RGB cameras (120° wide-angle, 2 MP 3D imaging), bumper, built-in GPS (location tracking), weather/rain sensing, lift detection |
| Connectivity | MOVAhome App; built-in 4G with 3-year free service; GPS location tracking; AirTag compatible |
| Software / AI | UltraView 3.0: 360° 3D LiDAR + AI dual vision; RTK-free, no boundary wire |
Images
martti
martti
martti
martti
martti
marttiImage Contributions
Videos
ROBOT FORUMS
Loading forums...
RATINGS
FREQUENTLY ASKED QUESTIONS
What is the MOVA LiDAX Ultra AWD?
All-wheel-drive robotic lawn mower series from MOVA for larger and sloped residential lawns, offered in variants rated for 1000, 1600 and 2000 m² per map (US: 2000 AWD at 0.5 acre and 3000 AWD at 0.75 acre). All variants share the same 740 × 532 × 321 mm, 23.6 kg body and battery.
Who makes the MOVA LiDAX Ultra AWD?
The MOVA LiDAX Ultra AWD is made by MOVA, a robotics company based in China.
How much does the MOVA LiDAX Ultra AWD cost?
Pricing for the MOVA LiDAX Ultra AWD ranges from $1,799 to $2,199.
What is the MOVA LiDAX Ultra AWD used for?
The MOVA LiDAX Ultra AWD is designed for agriculture, mapping, and navigation. It is used in consumer, agriculture, and homes settings.
How much does the MOVA LiDAX Ultra AWD weigh?
The MOVA LiDAX Ultra AWD weighs 23.6 kg.
What is the battery life of the MOVA LiDAX Ultra AWD?
The MOVA LiDAX Ultra AWD runs for about 170 minutes on a charge.
