Jianghuai Smart Shadow Micro Unmanned Helicopter
DESCRIPTION
Jianghuai Smart Shadow Micro Unmanned Helicopter is a Security from Jianghuai Laboratory. It is built for Inspection, Monitoring, Confined space inspection. Key figures: 0.1 kg, 30 min runtime.
Smart Shadow is a micro unmanned helicopter that weighs under 100 grams — small enough to fly inside a collapsed building or a duct, which is precisely the point. At 188 x 72 x 58 mm it is designed for spaces a conventional drone cannot enter, and the design priorities follow: under 60 dB of flight noise at one metre so it can observe without announcing itself, wind resistance above force 5 so it stays usable outdoors despite its mass, and over 30 minutes of cruise, which is remarkable at this scale. Sensing is unusually complete for the weight — a 1920 x 1080 RGB camera, a 256 x 192 thermal imager and a TOF depth sensor, fused for dual-spectrum target recognition — backed by 6 TOPS of onboard AI, autonomous perception and exploration, path planning at better than 5 Hz, and environment reconstruction accurate to under 2 m per 100 m travelled. One-button take-off and return keep it usable by an operator who is not a pilot. Jianghuai aims it at confined-space inspection, post-disaster search and rescue, counter-terrorism entry and precision agriculture.
FEATURES
- Whole-aircraft weight of 100 g or less
- 188 x 72 x 58 mm
- Cruise time of 30 minutes or more
- Communication range of 2 km or more
- Wind resistance of force 5 or above
- Maximum flight speed of 15 m/s or more
- Flight noise under 60 dB at 1 metre
- IP55 environmental protection
- RGB camera 1920 x 1080 at 30 FPS
- infrared 256 x 192 at 30 FPS
- TOF 30 x 30 at 15 FPS
- Onboard AI processing of 6 TOPS or more
- Dual-spectrum infrared and visible-light fused target recognition
- Autonomous path planning at better than 5 Hz
- Environment reconstruction and positioning error under 2 m per 100 m
- One-button take-off and return
- Applications: confined-space inspection, post-disaster rescue, counter-terrorism assault and precision agriculture
TECHNICAL SPECIFICATIONS
| Physical | |
| Weight | 0.1 kg |
|---|---|
| Dimensions | L 188 mm × W 72 mm × H 58 mm |
| Mobility | |
| Movement Type | Aerial |
| Speed | 54 km/h |
| Environment | Confined indoor spaces, disaster sites and outdoor use; IP55; wind resistance force 5 or above |
| Actuators | Micro unmanned helicopter rotor configuration with miniaturised drive and transmission components |
| Power | |
| Battery Life | ≥30 min |
| Sensing & Compute | |
| Sensors | RGB camera 1920x1080 30 FPS, infrared camera 256x192 30 FPS, TOF sensor 30x30 15 FPS |
| Software / AI | Autonomous perception, exploration and path planning; dual-spectrum target recognition; one-button take-off and return |
ROBOT FORUMS
Loading forums...
TECHNICAL SPECIFICATIONS
| Physical | |
| Weight | 0.1 kg |
|---|---|
| Dimensions | L 188 mm × W 72 mm × H 58 mm |
| Mobility | |
| Movement Type | Aerial |
| Speed | 54 km/h |
| Environment | Confined indoor spaces, disaster sites and outdoor use; IP55; wind resistance force 5 or above |
| Actuators | Micro unmanned helicopter rotor configuration with miniaturised drive and transmission components |
| Power | |
| Battery Life | ≥30 min |
| Sensing & Compute | |
| Sensors | RGB camera 1920x1080 30 FPS, infrared camera 256x192 30 FPS, TOF sensor 30x30 15 FPS |
| Software / AI | Autonomous perception, exploration and path planning; dual-spectrum target recognition; one-button take-off and return |
Images
martti
Image Contributions
Videos
ROBOT FORUMS
Loading forums...
RATINGS
FREQUENTLY ASKED QUESTIONS
What is the Jianghuai Smart Shadow Micro Unmanned Helicopter?
Smart Shadow is a micro unmanned helicopter that weighs under 100 grams — small enough to fly inside a collapsed building or a duct, which is precisely the point.
Who makes the Jianghuai Smart Shadow Micro Unmanned Helicopter?
The Jianghuai Smart Shadow Micro Unmanned Helicopter is made by Jianghuai Laboratory, a robotics company based in China.
How much does the Jianghuai Smart Shadow Micro Unmanned Helicopter cost?
Jianghuai Laboratory has not publicly announced pricing for the Jianghuai Smart Shadow Micro Unmanned Helicopter. You can enquire through RobotAIGeek for current pricing.
What is the Jianghuai Smart Shadow Micro Unmanned Helicopter used for?
The Jianghuai Smart Shadow Micro Unmanned Helicopter is designed for inspection, monitoring, confined space inspection, and post-disaster search and rescue. It is used in research, agriculture, and security & patrol settings.
How much does the Jianghuai Smart Shadow Micro Unmanned Helicopter weigh?
The Jianghuai Smart Shadow Micro Unmanned Helicopter weighs 0.1 kg.
How fast is the Jianghuai Smart Shadow Micro Unmanned Helicopter?
The Jianghuai Smart Shadow Micro Unmanned Helicopter can move at speeds of up to 54 km/h.
What is the battery life of the Jianghuai Smart Shadow Micro Unmanned Helicopter?
The Jianghuai Smart Shadow Micro Unmanned Helicopter runs for ≥30 min on a charge.
