DESCRIPTION
AFL is an Industrial-Robot from Rapyuta Robotics. It is built for Intralogistics, Lifting, Loading. Key figures: 1350 kg payload.
The Rapyuta AFL is Rapyuta Robotics' autonomous forklift, built on its rapyuta.io platform to move pallets in existing warehouses with no reflectors or magnetic tape: it scans 360 degrees with LiDAR and uses the laser point cloud to localise itself and detect obstacles, so it can be deployed quickly and adapted when layouts change. It handles pallets of any material and size, including steel-frame pallets, loads and unloads standard racks, flat storage areas and conveyors, stacks and unstacks at random heights and can 'double stack' to place a pallet further out when it cannot stop close to a conveyor. It lifts up to 1.35 tonnes to 4.5 m, passes through aisles with only 150-200 mm side clearance and 50 mm behind, and has moved about 30 pallets an hour at customer sites, including night shifts. A lithium-ion battery recharges in three hours and the AFL docks itself to charge; it integrates with a WMS, runs in Japanese or English and is backed by 24/7 support.
FEATURES
- Payload 1,350 kg
- lifting height 4.5 m
- LiDAR self-positioning: no reflectors or magnetic tape
- 360-degree laser scan for obstacles
- Handles all pallet types incl. steel-frame pallets
- racks, floor storage, conveyors
- random-height stacking
- double stacking
- Narrow clearance: 150-200 mm each side, 50 mm behind
- About 30 pallets per hour at deployment sites
- Automatic charging
- Li-ion battery, 3 h charge
- WMS integration
- Japanese / English interface
- 24/7 support
- Indoor operation 0-40 C
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Payload | 1350 kg |
|---|---|
| Mobility | |
| Movement Type | Wheeled |
| Environment | Indoor warehouses, 0-40 C |
| Power | |
| Battery Life | Lithium-ion |
| Charging Type | Automatic return to charging port; 3 h |
| Sensing & Compute | |
| Sensors | 3D LiDAR |
| Connectivity | rapyuta.io cloud platform; WMS integration |
ROBOT FORUMS
Loading forums...
TECHNICAL SPECIFICATIONS
Verified| Physical | |
| Payload | 1350 kg |
|---|---|
| Mobility | |
| Movement Type | Wheeled |
| Environment | Indoor warehouses, 0-40 C |
| Power | |
| Battery Life | Lithium-ion |
| Charging Type | Automatic return to charging port; 3 h |
| Sensing & Compute | |
| Sensors | 3D LiDAR |
| Connectivity | rapyuta.io cloud platform; WMS integration |
Images
martti
martti
martti
martti
martti
martti
marttiImage Contributions
Videos
ROBOT FORUMS
Loading forums...
RATINGS
FREQUENTLY ASKED QUESTIONS
What is the AFL?
The Rapyuta AFL is Rapyuta Robotics' autonomous forklift, built on its rapyuta.io platform to move pallets in existing warehouses with no reflectors or magnetic tape: it scans 360 degrees with LiDAR and uses the laser point cloud to localise itself and detect obstacles, so it can be deployed quickly and adapted when la…
Who makes the AFL?
The AFL is made by Rapyuta Robotics, a robotics company based in Japan.
How much does the AFL cost?
Rapyuta Robotics has not publicly announced pricing for the AFL. You can enquire through RobotAIGeek for current pricing.
What is the AFL used for?
The AFL is designed for intralogistics, lifting, loading, and material-handling. It is used in warehouse & logistics and manufacturing settings.
What is the payload capacity of the AFL?
The AFL has a payload capacity of 1,350 kg.
