The Composite Robot is iSAGEBOT's mobile base with a collaborative arm on top — what the company calls hand-eye-foot-brain coordination. It combines mobility, grasping and transfer in one machine, with a 20 kg rated load at the cobot tip, visual positioning accurate to 0.5 mm and navigation to 5 mm. iSAGEBOT claims one unit replaces two workers per shift and enables round-the-clock unmanned operation, improving efficiency by up to 60 percent. It is 800 by 600 by 750 mm and weighs 250 kg, moves at up to 1.5 m/s and runs on a 40 Ah battery, communicating over 4G, 5G or Wi-Fi. Its selling point operationally is that it needs no environmental modification: SLAM navigation means it deploys into existing facilities rather than requiring them to be rebuilt around it. Various grippers can be fitted for confined-space picking and placing.
주요 기능
- Collaborative arm on an autonomous mobile base
- Cobot tip rated load 20 kg
- Visual positioning accuracy 0.5 mm
- navigation accuracy 5 mm
- Dimensions 800 x 600 x 750 mm
- weight 250 kg
- Moving speed up to 1.5 m/s
- 40 Ah battery
- 4G, 5G and Wi-Fi communication
- SLAM navigation with no environmental modification required
- Interchangeable grippers for confined-space picking and placing
- Unified control and centralised power supply
- Human-robot interaction with robotic safety protection
기술 사양
검증됨| 물리 사양 | |
| 무게 | 250 kg |
|---|---|
| 크기 | L 800 mm × W 600 mm × H 750 mm |
| 가반하중 | 20 kg |
| 이동성 | |
| 이동 방식 | 바퀴형 |
| 속도 | 5.4 km/h |
| 조작 능력 | 높음 |
| 작동 환경 | Auto parts, semiconductor, FMCG, 3C electronics, biomedical, library and hospital settings |
| 액추에이터 | Wheeled autonomous base carrying a collaborative arm with interchangeable grippers |
| 센싱 & 컴퓨팅 | |
| 센서 | vision system, LiDAR |
| 소프트웨어 / AI | SLAM navigation; unified control across base and arm |
기술 사양
검증됨| 물리 사양 | |
| 무게 | 250 kg |
|---|---|
| 크기 | L 800 mm × W 600 mm × H 750 mm |
| 가반하중 | 20 kg |
| 이동성 | |
| 이동 방식 | 바퀴형 |
| 속도 | 5.4 km/h |
| 조작 능력 | 높음 |
| 작동 환경 | Auto parts, semiconductor, FMCG, 3C electronics, biomedical, library and hospital settings |
| 액추에이터 | Wheeled autonomous base carrying a collaborative arm with interchangeable grippers |
| 센싱 & 컴퓨팅 | |
| 센서 | vision system, LiDAR |
| 소프트웨어 / AI | SLAM navigation; unified control across base and arm |
이미지
martti
martti
martti
martti이미지 기여
동영상
로봇 포럼
포럼 불러오는 중...
평가
자주 묻는 질문
What is the iSAGEBOT Composite Robot?
The Composite Robot is iSAGEBOT's mobile base with a collaborative arm on top — what the company calls hand-eye-foot-brain coordination. It combines mobility, grasping and transfer in one machine, with a 20 kg rated load at the cobot tip, visual positioning accurate to 0.5 mm and navigation to 5 mm.
Who makes the iSAGEBOT Composite Robot?
The iSAGEBOT Composite Robot is made by Isagebot, a robotics company based in China.
How much does the iSAGEBOT Composite Robot cost?
Isagebot has not publicly announced pricing for the iSAGEBOT Composite Robot. You can enquire through RobotAIGeek for current pricing.
What is the iSAGEBOT Composite Robot used for?
The iSAGEBOT Composite Robot is designed for 머신 텐딩, 자재 취급, 픽앤플레이스, and 운반. It is used in 전자, 헬스케어, 창고·물류, and 제조 settings.
What is the payload capacity of the iSAGEBOT Composite Robot?
The iSAGEBOT Composite Robot has a payload capacity of 20 kg.
How much does the iSAGEBOT Composite Robot weigh?
The iSAGEBOT Composite Robot weighs 250 kg.
How fast is the iSAGEBOT Composite Robot?
The iSAGEBOT Composite Robot can move at speeds of up to 5.4 km/h.
