説明
SGLS-C3はSevnce RoboticsのIndustrial-Robotです。 点検、巡回、Explosion-proof inspection and emergency robotics向けに設計されています。 主な数値：450 kg、稼働時間 300 分。
The SGLS-C3 is Sevnce's modular explosion-proof wheeled inspection robot rated for IIC gas groups (Ex IIC T6 Gb, IP66). It integrates different instruments for leak ('running, emitting, dripping, leaking') detection, equipment and personnel safety, site security and equipment-state checks, has an ultrasonic omnidirectional anti-collision system and can carry an AI industrial PC for millisecond-level recognition. Four-wheel drive gives up to 1.4 m/s with a 1.6 m turning circle; it climbs 25-degree slopes and 10 cm obstacles, wades 12 cm, navigates by laser to +/-3 cm and runs up to five hours with up to three-hour charging between -20 and 60 C. It measures up to 1,250 x 960 x 920 mm and 450 kg. Standard functions include autonomous inspection, obstacle avoidance, remote control, video monitoring, offline inspection, sound-and-light alarm, auxiliary lighting, autonomous charging, two-way voice and one-key return, with options for laser gas telemetry, laser vibration measurement, optical and acoustic imaging, voiceprint and noise detection and flame detection, a lifting gimbal, BeiDou navigation and a robot arm.
特長
- Explosion protection Ex IIC T6 Gb
- IP66
- Modular payload integration
- optional AI industrial PC
- Ultrasonic omnidirectional anti-collision
- Four-wheel drive
- Up to 1,250 x 960 x 920 mm
- up to 450 kg
- Speed up to 1.4 m/s
- turning diameter 160 cm
- Slopes up to 25 deg
- obstacles up to 10 cm
- wading 12 cm
- Laser navigation
- accuracy +/-3 cm
- Runtime up to 5 h
- charging up to 3 h
- Options: laser telemetry and vibration, imaging, voiceprint, noise, flame detection, lifting gimbal, BeiDou, robot arm
技術仕様
検証済み| 本体 | |
| 重量 | 450 kg |
|---|---|
| 寸法 | L 1.25 m × W 960 mm × H 920 mm |
| 移動性能 | |
| 移動方式 | 車輪型 |
| 速度 | 5.04 km/h |
| 使用環境 | Explosive and hazardous industrial sites (oil, chemical, gas, power), indoor and outdoor |
| 電源 | |
| バッテリー駆動時間 | 300 min |
| センシング・演算 | |
| センサー | 2D LiDAR (laser navigation), ultrasonic sensors, cameras |
ロボットフォーラム
フォーラムを読み込み中...
技術仕様
検証済み| 本体 | |
| 重量 | 450 kg |
|---|---|
| 寸法 | L 1.25 m × W 960 mm × H 920 mm |
| 移動性能 | |
| 移動方式 | 車輪型 |
| 速度 | 5.04 km/h |
| 使用環境 | Explosive and hazardous industrial sites (oil, chemical, gas, power), indoor and outdoor |
| 電源 | |
| バッテリー駆動時間 | 300 min |
| センシング・演算 | |
| センサー | 2D LiDAR (laser navigation), ultrasonic sensors, cameras |
画像
martti
martti
martti
martti
martti投稿画像
動画
ロボットフォーラム
フォーラムを読み込み中...
評価
よくある質問
What is the SGLS-C3?
The SGLS-C3 is Sevnce's modular explosion-proof wheeled inspection robot rated for IIC gas groups (Ex IIC T6 Gb, IP66). It integrates different instruments for leak ('running, emitting, dripping, leaking') detection, equipment and personnel safety, site security and equipment-state checks, has an ultrasonic omnidirecti…
Who makes the SGLS-C3?
The SGLS-C3 is made by Sevnce Robotics, a robotics company based in China.
How much does the SGLS-C3 cost?
Sevnce Robotics has not publicly announced pricing for the SGLS-C3. You can enquire through RobotAIGeek for current pricing.
What is the SGLS-C3 used for?
The SGLS-C3 is designed for 点検, 巡回, and explosion-proof inspection and emergency robotics. It is used in エネルギー and 製造 settings.
How much does the SGLS-C3 weigh?
The SGLS-C3 weighs 450 kg.
How fast is the SGLS-C3?
The SGLS-C3 can move at speeds of up to 5.04 km/h.
What is the battery life of the SGLS-C3?
The SGLS-C3 runs for about 300 minutes on a charge.
