Four-Way Pallet Shuttle
BESCHREIBUNG
BlueSword Four-Way Pallet Shuttle is a rail-guided omnidirectional robot for dense pallet AS/RS storage, retrieval, and aisle switching.
FUNKTIONEN
- 1,150 × 980 × 135 mm body
- 350 kg body weight
- Speed 1.5 m/s
- Acceleration 0.3 m/s²
- ±2 mm positioning accuracy
- 2.5 s lifting and direction change
- LFP battery
- Over 8 h runtime
- Under 2 h charging
- 2,000+ battery cycles
- Current OEM material conflicts on standard payload (1.5 t versus 1.6 t)
- While both cite customization up to 3 t
- So payload is deliberately not mapped to a typed field
- Features 16-wheel four-way drive
- Opportunity charging
- Sealed modular construction
- And low-temperature/explosion-proof options
TECHNISCHE DATEN
| Physisch | |
| Gewicht | 350 kg |
|---|---|
| Abmessungen | L 1.15 m × W 980 mm × H 135 mm |
| Mobilität | |
| Bewegungsart | Radbasiert |
| Geschwindigkeit | 5.4 km/h |
| Manipulation | Mittel |
TECHNISCHE DATEN
| Physisch | |
| Gewicht | 350 kg |
|---|---|
| Abmessungen | L 1.15 m × W 980 mm × H 135 mm |
| Mobilität | |
| Bewegungsart | Radbasiert |
| Geschwindigkeit | 5.4 km/h |
| Manipulation | Mittel |
Bilder
martti
Bildbeiträge
Videos
ROBOTER-FOREN
Foren werden geladen...
BEWERTUNGEN
HÄUFIG GESTELLTE FRAGEN
What is the Four-Way Pallet Shuttle?
BlueSword Four-Way Pallet Shuttle is a rail-guided omnidirectional robot for dense pallet AS/RS storage, retrieval, and aisle switching.
Who makes the Four-Way Pallet Shuttle?
The Four-Way Pallet Shuttle is made by Bluesword Intelligent Technology Co., Ltd, a robotics company based in China.
How much does the Four-Way Pallet Shuttle cost?
Bluesword Intelligent Technology Co., Ltd has not publicly announced pricing for the Four-Way Pallet Shuttle. You can enquire through RobotAIGeek for current pricing.
What is the Four-Way Pallet Shuttle used for?
The Four-Way Pallet Shuttle is designed for intralogistik, materialhandhabung, and palettentransport. It is used in lager & logistik and fertigung settings.
How much does the Four-Way Pallet Shuttle weigh?
The Four-Way Pallet Shuttle weighs 350 kg.
How fast is the Four-Way Pallet Shuttle?
The Four-Way Pallet Shuttle can move at speeds of up to 5.4 km/h.
