描述
The Geek+ RS11-DA is a wheeled robot from Geek+ Technology Co., Ltd. This robot is designed for automated tote handling and storage access, primarily within high-density warehouses. Its differentiating features include a vertical lifting structure that allows for precise positioning and stable navigation. This navigation is achieved through a combination of inertial and QR code guidance, enabling fast, accurate, and safe access to multi-level storage locations. The RS11-DA reliably adapts to standardized indoor operating conditions. Deployment evidence for this robot is available. It is applicable across various industries, including logistics, retail, e-commerce, 3PL, footwear, and pharmaceuticals.
功能特色
- Maximum payload 40 kg
- Maximum speed with load 1.2 m/s (4.32 km/h)
- 1.8 m/s (6.48 km/h) unloaded
- Minimum lifting time 12 s
- Maximum lifting height 10765 mm
- Dimensions 1800 x 1000 x 6200 mm
- Weight 970 kg
- Tallest RoboShuttle in the range, for high-bay tote storage
技術規格
已驗證| 物理參數 | |
| 重量 | 970 kg |
|---|---|
| 外形尺寸 | H 6.2 m |
| 負載 | 40 kg |
| 臂展 | 3 m |
| 移動能力 | |
| 移動類型 | 帶輪的 |
| 速度 | 4.32 km/h |
技術規格
已驗證| 物理參數 | |
| 重量 | 970 kg |
|---|---|
| 外形尺寸 | H 6.2 m |
| 負載 | 40 kg |
| 臂展 | 3 m |
| 移動能力 | |
| 移動類型 | 帶輪的 |
| 速度 | 4.32 km/h |
圖片
martti
圖片貢獻
機器人論壇
正在載入論壇...
評分
常見問題
What is the Geek+ RS11-DA?
The Geek+ RS11-DA is a wheeled robot from Geek+ Technology Co., Ltd. This robot is designed for automated tote handling and storage access, primarily within high-density warehouses. Its differentiating features include a vertical lifting structure that allows for precise positioning and stable navigation.
Who makes the Geek+ RS11-DA?
The Geek+ RS11-DA is made by Geek+ Technology Co., Ltd. (Geekplus Technology Co.), a robotics company based in China.
How much does the Geek+ RS11-DA cost?
Geek+ Technology Co., Ltd. (Geekplus Technology Co.) has not publicly announced pricing for the Geek+ RS11-DA. You can enquire through RobotAIGeek for current pricing.
What is the Geek+ RS11-DA used for?
The Geek+ RS11-DA is designed for 內部物流, 物料搬運, 送貨, and 採摘. It is used in 物流 and 製造業 settings.
What is the payload capacity of the Geek+ RS11-DA?
The Geek+ RS11-DA has a payload capacity of 40 kg and a reach of 3 m.
How much does the Geek+ RS11-DA weigh?
The Geek+ RS11-DA weighs 970 kg.
How fast is the Geek+ RS11-DA?
The Geek+ RS11-DA can move at speeds of up to 4.32 km/h.
