描述
TX2-60L MedX Ready is Stäubli's medical-ready long-reach TX2-60L variant for patient-care and medical-device automation aligned with ISO 13485:2016 MedX Ready offerings.
功能特点
- 3.7 kg load capacity
- 920 mm reach at wrist
- ±0.02 mm repeatability (ISO 9283)
- 53 kg arm mass
- 6 axes
- MedX Ready configuration for medical robotics
- CS9 LP controller family.
技术规格
| 物理参数 | |
| 重量 | 53 kg |
|---|---|
| 负载 | 3.7 kg |
| 臂展 | 920 mm |
| 重复定位精度 | ±0.02 mm |
| 移动能力 | |
| 运动类型 | 文具 |
| 自由度 | 6 |
| 操作能力 | 高 |
技术规格
| 物理参数 | |
| 重量 | 53 kg |
|---|---|
| 负载 | 3.7 kg |
| 臂展 | 920 mm |
| 重复定位精度 | ±0.02 mm |
| 移动能力 | |
| 运动类型 | 文具 |
| 自由度 | 6 |
| 操作能力 | 高 |
机器人论坛
正在加载论坛...
评分
常见问题
What is the TX2-60L MedX Ready?
TX2-60L MedX Ready is Stäubli's medical-ready long-reach TX2-60L variant for patient-care and medical-device automation aligned with ISO 13485:2016 MedX Ready offerings.
Who makes the TX2-60L MedX Ready?
The TX2-60L MedX Ready is made by Stäubli, a robotics company based in Switzerland.
How much does the TX2-60L MedX Ready cost?
Stäubli has not publicly announced pricing for the TX2-60L MedX Ready. You can enquire through RobotAIGeek for current pricing.
What is the TX2-60L MedX Ready used for?
The TX2-60L MedX Ready is designed for 拾放, 研究, 外科手术, and 帮助. It is used in 研究 and 医疗保健 settings.
What is the payload capacity of the TX2-60L MedX Ready?
The TX2-60L MedX Ready has a payload capacity of 3.7 kg and a reach of 920 mm.
How much does the TX2-60L MedX Ready weigh?
The TX2-60L MedX Ready weighs 53 kg.
How many degrees of freedom does the TX2-60L MedX Ready have?
The TX2-60L MedX Ready has 6 degrees of freedom.
When was the TX2-60L MedX Ready released?
The TX2-60L MedX Ready was released in 2026.
