描述
Racer-3-0.63是Comau的Industrial-Robot。 面向采摘设计。 关键数据：30 kg、负载 3 kg、臂展 630 mm、6 自由度。
Comau's Racer-3-0.63 is a stationary industrial arm built for factory automation, supporting collaborative and mobile robotics integration across diverse production environments.
功能特点
- Comau Racer-3-0.63 is a compact, high-speed six-axis industrial robot for assembly, material handling and light manufacturing where cycle time and precision matter
- Technical specifications (Comau datasheet): maximum wrist payload 3 kg
- additional forearm load 2 kg
- maximum horizontal reach 630 mm
- repeatability +/-0.02 mm
- robot weight 30 kg
- 6 axes
- protection IP54
- mounting Floor / Ceiling / Sloping / Wall
技术规格
已验证| 物理参数 | |
| 重量 | 30 kg |
|---|---|
| 负载 | 3 kg |
| 臂展 | 630 mm |
| 重复定位精度 | ±0.02 mm |
| 移动能力 | |
| 运动类型 | 文具 |
| 自由度 | 6 |
| 操作能力 | 高 |
| 作业环境 | IP54 |
技术规格
已验证| 物理参数 | |
| 重量 | 30 kg |
|---|---|
| 负载 | 3 kg |
| 臂展 | 630 mm |
| 重复定位精度 | ±0.02 mm |
| 移动能力 | |
| 运动类型 | 文具 |
| 自由度 | 6 |
| 操作能力 | 高 |
| 作业环境 | IP54 |
martti
martti
martti
martti图片贡献
机器人论坛
正在加载论坛...
评分
常见问题
What is the Racer-3-0.63?
Comau's Racer-3-0.63 is a stationary industrial arm built for factory automation, supporting collaborative and mobile robotics integration across diverse production environments.
Who makes the Racer-3-0.63?
The Racer-3-0.63 is made by Comau, a robotics company based in Italy.
How much does the Racer-3-0.63 cost?
Comau has not publicly announced pricing for the Racer-3-0.63. You can enquire through RobotAIGeek for current pricing.
What is the Racer-3-0.63 used for?
The Racer-3-0.63 is designed for 采摘. It is used in 制造业 settings.
What is the payload capacity of the Racer-3-0.63?
The Racer-3-0.63 has a payload capacity of 3 kg and a reach of 630 mm.
How much does the Racer-3-0.63 weigh?
The Racer-3-0.63 weighs 30 kg.
How many degrees of freedom does the Racer-3-0.63 have?
The Racer-3-0.63 has 6 degrees of freedom.
