설명
TS2-40 is Stäubli's modular 4-axis SCARA robot with encapsulated JCS drive technology, ultra-short cycle times, and CS9 controller compatibility shared with the TX2 6-axis line.
주요 기능
- 8.4 kg load capacity
- 460 mm reach (axis 1–4)
- ±0.01 mm X-Y repeatability (ISO 9283)
- 38 kg arm mass
- up to 240 cycles/min (25-300-25 mm / 2 kg)
- 200 or 400 mm stroke option
- protection up to IP65
- floor/ceiling mounting
- CS9 SE or LP controller
- optional SIL3-PLe safety functions.
기술 사양
| 물리 사양 | |
| 무게 | 38 kg |
|---|---|
| 가반하중 | 8.4 kg |
| 도달거리 | 460 mm |
| 반복 정밀도 | ±0.01 mm |
| 이동성 | |
| 이동 방식 | 고정형 |
| 자유도 | 4 |
| 조작 능력 | 높음 |
기술 사양
| 물리 사양 | |
| 무게 | 38 kg |
|---|---|
| 가반하중 | 8.4 kg |
| 도달거리 | 460 mm |
| 반복 정밀도 | ±0.01 mm |
| 이동성 | |
| 이동 방식 | 고정형 |
| 자유도 | 4 |
| 조작 능력 | 높음 |
이미지
로봇 포럼
포럼 불러오는 중...
평가
자주 묻는 질문
What is the TS2-40?
TS2-40 is Stäubli's modular 4-axis SCARA robot with encapsulated JCS drive technology, ultra-short cycle times, and CS9 controller compatibility shared with the TX2 6-axis line.
Who makes the TS2-40?
The TS2-40 is made by Stäubli, a robotics company based in Switzerland.
How much does the TS2-40 cost?
Stäubli has not publicly announced pricing for the TS2-40. You can enquire through RobotAIGeek for current pricing.
What is the TS2-40 used for?
The TS2-40 is designed for 조립, 적재, 자재 취급, and 포장. It is used in 제조 settings.
What is the payload capacity of the TS2-40?
The TS2-40 has a payload capacity of 8.4 kg and a reach of 460 mm.
How much does the TS2-40 weigh?
The TS2-40 weighs 38 kg.
How many degrees of freedom does the TS2-40 have?
The TS2-40 has 4 degrees of freedom.
When was the TS2-40 released?
The TS2-40 was released in 2019.
