Peitian AIR7-920

Peitian Robot
Industrial-RobotChinaChina출시됨
Peitian AIR7-920
비교
출처:
cdn.robotaigeek.com
산업:
연구제조
용도:
조립픽앤플레이스Loading and unloadinghandlingpalletisinginjection mouldingweldinggrinding and polishingdispensingpacking
가격:
미공개

설명

The AIR7-920 is a small-payload six-axis articulated arm from Peitian's AIR range, carrying 7 kg to a reach of 920 mm. Peitian quotes position repeatability of ±0.02mm, which is the figure that decides whether an arm of this size can be trusted on close-tolerance work rather than only on gross handling. The manipulator weighs 53 kg. It is sealed to IP67, and can be mounted Floor or wall or ceiling. It runs on Peitian's inCube20 / ARC5-12 controller cabinet. AIR7-920 is especially suitable for multi-station operation in 3C field, such as loading & unloading, handling, palletizing, grinding and polishing, as well as sorting and palletizing in intelligent storage field.

주요 기능

  • Six-axis articulated industrial robot arm
  • Rated payload 7 kg
  • Maximum reach 920 mm
  • Manipulator weight 53 kg
  • Position repeatability ±0.02mm
  • Ingress protection IP67
  • Mounting: Floor / wall / ceiling
  • Compatible controller cabinets: inCube20 / ARC5-12
  • Working range Axis 1 rotation -170°/+170°
  • Axis 2 arm -100°/+135°
  • Axis 3 arm -120°/+156°
  • Axis 4 wrist -200°/+200°
  • Axis 5 bend -135°/+135°
  • Axis 6 turn -360°/+360°
  • Rotation rate Axis 1 rotation 380°/s
  • Axis 2 arm 320°/s
  • Axis 3 arm 390°/s
  • Axis 4 wrist 490°/s
  • Axis 5 bend 565°/s
  • Axis 6 turn 815°/s
  • Ambient temperature 0 to 45 degrees Celsius, humidity up to 95% non-condensing, altitude up to 1000 m
  • No corrosive, flammable or explosive gases permitted in the operating environment
  • AIR7-920 is especially suitable for multi-station operation in 3C field, such as loading & unloading, handling, palletizing, grinding and polishing, as well as sorting and palletizing in intelligent storage field.

기술 사양

물리 사양
무게53 kg
가반하중7 kg
도달거리920 mm
이동성
이동 방식고정형
자유도6
조작 능력높음
작동 환경Industrial indoor use, 0 to 45 degrees Celsius, humidity up to 95% non-condensing, altitude up to 1000 m; no corrosive, flammable or explosive gases
액추에이터6-axis six-axis articulated manipulator, mounted Floor or wall or ceiling
센싱 & 컴퓨팅
소프트웨어 / AIDriven by Peitian inCube20 / ARC5-12 controller cabinets
제조사 출처서드파티 출처출처 없음출처 상태는 이 로봇에 등록된 출처를 기준으로 합니다.

자주 묻는 질문

What is the Peitian AIR7-920?

The AIR7-920 is a small-payload six-axis articulated arm from Peitian's AIR range, carrying 7 kg to a reach of 920 mm. Peitian quotes position repeatability of ±0.02mm, which is the figure that decides whether an arm of this size can be trusted on close-tolerance work rather than only on gross handling.

Who makes the Peitian AIR7-920?

The Peitian AIR7-920 is made by Peitian Robot, a robotics company based in China.

How much does the Peitian AIR7-920 cost?

Peitian Robot has not publicly announced pricing for the Peitian AIR7-920. You can enquire through RobotAIGeek for current pricing.

What is the Peitian AIR7-920 used for?

The Peitian AIR7-920 is designed for 조립, 픽앤플레이스, loading and unloading, and handling. It is used in 연구 and 제조 settings.

What is the payload capacity of the Peitian AIR7-920?

The Peitian AIR7-920 has a payload capacity of 7 kg and a reach of 920 mm.

How much does the Peitian AIR7-920 weigh?

The Peitian AIR7-920 weighs 53 kg.

How many degrees of freedom does the Peitian AIR7-920 have?

The Peitian AIR7-920 has 6 degrees of freedom.
