설명
Mouse/Tunnel High is the 1,000 kg omnidirectional model in Bluepath Robotics' low-clearance AMR line, built by Bluepath Robotics of Istanbul, Turkey. At 2,100 x 500 x 230 mm it drives under carts and racks like the Low variant, but adds omnidirectional movement and a bidirectional pin system that engages a load from either side — which removes the turning and repositioning a single-sided tugger needs in a tunnel-shaped aisle. Hybrid navigation combines natural SLAM with line tracking, so it stays flexible on changing layouts and repeatable on fixed ones, at up to 1.5 m/s. Source: https://bluepathrobotics.com/product/mouse-tunnel-high-amr/
주요 기능
- Tows up to 1,000 kg with a bidirectional pin system engaged from either side
- 230 mm tall, 2,100 x 500 mm footprint for tunnel-shaped and under-rack aisles
- Omnidirectional drive at up to 1.5 m/s
- hybrid natural-SLAM and line-tracking navigation
- Natural SLAM navigation — no floor magnets, reflectors or line tape required
- 3D object detection, dynamic map update and safe remote on/off
- VDA 5050 compatible
- scheduled from the Bluepath All-in-One Fleet Manager
- WMS/ERP integration and PLC/IoT interaction with smart charging scheduling
기술 사양
검증됨| 물리 사양 | |
| 무게 | 450 kg |
|---|---|
| 크기 | L 2.1 m × W 500 mm × H 230 mm |
| 가반하중 | 1000 kg |
| 이동성 | |
| 이동 방식 | 바퀴형 |
| 속도 | 5.4 km/h |
| 작동 환경 | Indoor factory and warehouse floors shared with people and vehicles |
| 센싱 & 컴퓨팅 | |
| 소프트웨어 / AI | Bluepath Robotic Software System with All-in-One Fleet Management; automated task management with manual override, shift management |
기술 사양
검증됨| 물리 사양 | |
| 무게 | 450 kg |
|---|---|
| 크기 | L 2.1 m × W 500 mm × H 230 mm |
| 가반하중 | 1000 kg |
| 이동성 | |
| 이동 방식 | 바퀴형 |
| 속도 | 5.4 km/h |
| 작동 환경 | Indoor factory and warehouse floors shared with people and vehicles |
| 센싱 & 컴퓨팅 | |
| 소프트웨어 / AI | Bluepath Robotic Software System with All-in-One Fleet Management; automated task management with manual override, shift management |
이미지
martti
martti
martti이미지 기여
로봇 포럼
포럼 불러오는 중...
평가
자주 묻는 질문
What is the Mouse/Tunnel High?
Mouse/Tunnel High is the 1,000 kg omnidirectional model in Bluepath Robotics' low-clearance AMR line, built by Bluepath Robotics of Istanbul, Turkey.
Who makes the Mouse/Tunnel High?
The Mouse/Tunnel High is made by Bluepath Robotics, a robotics company based in Turkey.
How much does the Mouse/Tunnel High cost?
Bluepath Robotics has not publicly announced pricing for the Mouse/Tunnel High. You can enquire through RobotAIGeek for current pricing.
What is the Mouse/Tunnel High used for?
The Mouse/Tunnel High is designed for 운반. It is used in 창고·물류 and 제조 settings.
What is the payload capacity of the Mouse/Tunnel High?
The Mouse/Tunnel High has a payload capacity of 1,000 kg.
How much does the Mouse/Tunnel High weigh?
The Mouse/Tunnel High weighs 450 kg.
How fast is the Mouse/Tunnel High?
The Mouse/Tunnel High can move at speeds of up to 5.4 km/h.
