Guoxing RXR-M150GD

Shandong Guoxing Intelligent Technology
Mobile-RobotsChinaChina출시됨
Guoxing RXR-M150GD
비교
출처:
gxsuprobot.com
산업:
에너지제조보안·순찰
용도:
점검모니터링Petrochemical oil depot and refinery firesrailway tunnel fireslarge-span factory firesunderground facility and yard fireslarge-scale toxic gas and smoke incidents
가격:
미공개

설명

The RXR-M150GD is the biggest gun Guoxing makes: 150 litres per second of water or foam thrown past 100 metres, from a two-tonne diesel machine on a four-wheel-drive hydraulic rubber track chassis. It exists to replace trailer-mounted and mobile monitors — instead of firefighters manhandling a monitor into position near a burning tank, the robot drives its own cannon there under remote control. The diesel engine is what buys the endurance and the flow: ten hours of working time against the five of the battery machines, with a maintenance-free water cooling system and fine mist self-protection. It crosses 500 mm obstacles, the highest in the catalogue, climbs stairs and slopes to 40 degrees, and moves at up to 12 km/h. Twelve kinds of gas detection are available as an option, alongside infrared ranging and four channels of imagery. Guoxing reports delivering thirty of these to Sinopec in a single batch.

주요 기능

  • Diesel-driven with an imported engine and maintenance-free water cooling
  • Up to 2300 x 1600 x 1400 mm and up to 2000 kg
  • Fire water cannon at 150 L/s, water and foam dual-purpose, range 100 metres or more
  • Water cannon pitch from -20 to +90 degrees with horizontal rotation over 180 degrees
  • Obstacle crossing height of 500 mm or more, the highest in the range, with ground clearance of 250 mm or more
  • Climbing or stairs up to 40 degrees and side tilt stability angle of 40 degrees or more
  • Driving speed from 0 to 12 km/h on a four-wheel drive ATV hydraulic rubber track chassis
  • Working time of 10 hours or more
  • Traction force of 15 kN or more
  • Fine mist self-protection system
  • Optional detection of 12 kinds of gas
  • infrared ranging and infrared imaging
  • Image collection and transmission on 4 channels or more
  • Illumination lights, 2 in front and 2 in the rear
  • automatic detachment of the water hose
  • Remote control distance 1000 m by panel operation
  • control box 10 inches or more, 12 V / 24 VDC, up to 5 kg, -20 to 60 degrees Celsius

기술 사양

물리 사양
무게2000 kg
크기L 2.3 m × W 1.6 m × H 1.4 m
이동성
이동 방식기타
속도11.99 km/h
작동 환경Large-scale industrial fires, tunnels and refineries; stairs and 40-degree slopes
액추에이터Four-wheel drive ATV hydraulic rubber track chassis with an imported diesel engine and a 150 L/s water and foam cannon
전원
배터리 지속 시간≥10 h
센싱 & 컴퓨팅
센서4-channel cameras, infrared ranging, infrared imaging, 12-gas detector (optional)
제조사 출처서드파티 출처출처 없음출처 상태는 이 로봇에 등록된 출처를 기준으로 합니다.

자주 묻는 질문

What is the Guoxing RXR-M150GD?

The RXR-M150GD is the biggest gun Guoxing makes: 150 litres per second of water or foam thrown past 100 metres, from a two-tonne diesel machine on a four-wheel-drive hydraulic rubber track chassis.

Who makes the Guoxing RXR-M150GD?

The Guoxing RXR-M150GD is made by Shandong Guoxing Intelligent Technology, a robotics company based in China.

How much does the Guoxing RXR-M150GD cost?

Shandong Guoxing Intelligent Technology has not publicly announced pricing for the Guoxing RXR-M150GD. You can enquire through RobotAIGeek for current pricing.

What is the Guoxing RXR-M150GD used for?

The Guoxing RXR-M150GD is designed for 점검, 모니터링, petrochemical oil depot and refinery fires, and railway tunnel fires. It is used in 에너지, 제조, and 보안·순찰 settings.

How much does the Guoxing RXR-M150GD weigh?

The Guoxing RXR-M150GD weighs 2,000 kg.

How fast is the Guoxing RXR-M150GD?

The Guoxing RXR-M150GD can move at speeds of up to 11.99 km/h.

What is the battery life of the Guoxing RXR-M150GD?

The Guoxing RXR-M150GD runs for ≥10 h on a charge.
