説明
Xynova Prima 1はXynovaのEnd-Effectorsです。 開発、マテリアルハンドリング、研究向けに設計されています。 主な数値：可搬質量 20 kg、22 自由度。
Xynova Prima 1 is a direct-drive dexterous robot hand from Hangzhou component maker Xynova, built 1:1 to human-hand scale (190 mm) for humanoid robots. Fully direct-drive joints with zero backlash give it millisecond response, a 1 kHz control bandwidth and a 0.08-second open/close cycle, and very low back-drive torque (0.04 Nm) makes it compliant and safe to touch. Its 22-DoF biomimetic configuration delivers 15 N of fingertip force across four fingers and lifts up to 20 kg, with 0.5 N force-control accuracy and 0.5 mm repeatability for native hybrid force-position control. All five fingers carry visuo-tactile sensing that captures fine contact changes at the fingertips as high-density feedback for manipulation learning.
特長
- 22-DoF biomimetic dexterous hand, 1:1 human scale (190 mm)
- Fully direct-drive, zero backlash
- 1 kHz response bandwidth
- 0.08 s open/close cycle
- Fingertip force 15 N across four fingers
- lifting payload up to 20 kg
- Force-control accuracy 0.5 N
- repeatability 0.5 mm
- native hybrid force-position control
- Five-finger visuo-tactile sensing with high-density fingertip feedback
- Minimum back-drive torque 0.04 Nm for compliant, safe interaction
技術仕様
検証済み| 本体 | |
| 可搬重量 | 20 kg |
|---|---|
| 移動性能 | |
| 移動方式 | 固定型 |
| 自由度 | 22 |
| 使用環境 | Mounted on humanoid or robot arms |
| アクチュエーター | Fully direct-drive finger joints |
| センシング・演算 | |
| センサー | five-finger visuo-tactile sensors |
ロボットフォーラム
フォーラムを読み込み中...
技術仕様
検証済み| 本体 | |
| 可搬重量 | 20 kg |
|---|---|
| 移動性能 | |
| 移動方式 | 固定型 |
| 自由度 | 22 |
| 使用環境 | Mounted on humanoid or robot arms |
| アクチュエーター | Fully direct-drive finger joints |
| センシング・演算 | |
| センサー | five-finger visuo-tactile sensors |
画像
martti
martti
martti
martti
martti投稿画像
動画
ロボットフォーラム
フォーラムを読み込み中...
評価
よくある質問
What is the Xynova Prima 1?
Xynova Prima 1 is a direct-drive dexterous robot hand from Hangzhou component maker Xynova, built 1:1 to human-hand scale (190 mm) for humanoid robots.
Who makes the Xynova Prima 1?
The Xynova Prima 1 is made by Xynova, a robotics company based in China.
How much does the Xynova Prima 1 cost?
Xynova has not publicly announced pricing for the Xynova Prima 1. You can enquire through RobotAIGeek for current pricing.
What is the Xynova Prima 1 used for?
The Xynova Prima 1 is designed for 開発, マテリアルハンドリング, 研究, and humanoid robot manipulation, teleoperation and manipulation-learning research. It is used in 研究 and 製造 settings.
What is the payload capacity of the Xynova Prima 1?
The Xynova Prima 1 has a payload capacity of 20 kg.
How many degrees of freedom does the Xynova Prima 1 have?
The Xynova Prima 1 has 22 degrees of freedom.
