BESCHREIBUNG
PL80 ist ein Industrial-Robot von YASKAWA Electric. Er ist für Materialhandhabung, Palettieren ausgelegt. Eckdaten: 565 kg, 80 kg Traglast, 2061 mm Reichweite, 5 Freiheitsgrade, erschienen 2021.
Yaskawa Motoman PL80 is a PL Series industrial robot with 80 kg payload and 2061 mm horizontal reach (565 kg mass, ±0.03 mm repeatability).
FUNKTIONEN
- Payload 80 kg
- Horizontal reach 2061 mm
- Vertical reach 3291 mm
- Mass 565 kg
- Repeatability ±0.03 mm
- 5 controlled axes
- Applications: Palletizing, Pick and Pack
TECHNISCHE DATEN
| Physisch | |
| Gewicht | 565 kg |
|---|---|
| Traglast | 80 kg |
| Reichweite | 2.06 m |
| Wiederholgenauigkeit | ±0.03 mm |
| Mobilität | |
| Bewegungsart | Stationär |
| Freiheitsgrade | 5 |
| Manipulation | Hoch |
TECHNISCHE DATEN
| Physisch | |
| Gewicht | 565 kg |
|---|---|
| Traglast | 80 kg |
| Reichweite | 2.06 m |
| Wiederholgenauigkeit | ±0.03 mm |
| Mobilität | |
| Bewegungsart | Stationär |
| Freiheitsgrade | 5 |
| Manipulation | Hoch |
Bilder
martti
Bildbeiträge
ROBOTER-FOREN
Foren werden geladen...
BEWERTUNGEN
HÄUFIG GESTELLTE FRAGEN
What is the PL80?
Yaskawa Motoman PL80 is a PL Series industrial robot with 80 kg payload and 2061 mm horizontal reach (565 kg mass, ±0.03 mm repeatability).
Who makes the PL80?
The PL80 is made by YASKAWA Electric, a robotics company based in Japan.
How much does the PL80 cost?
YASKAWA Electric has not publicly announced pricing for the PL80. You can enquire through RobotAIGeek for current pricing.
What is the PL80 used for?
The PL80 is designed for materialhandhabung and palettieren. It is used in automobilindustrie and fertigung settings.
What is the payload capacity of the PL80?
The PL80 has a payload capacity of 80 kg and a reach of 2.06 m.
How much does the PL80 weigh?
The PL80 weighs 565 kg.
How many degrees of freedom does the PL80 have?
The PL80 has 5 degrees of freedom.
When was the PL80 released?
The PL80 was released in 2021.
