BESCHREIBUNG
IRB 1200 Next Generation ist ein Industrial-Robot von ABB Robotics. Er ist für Montage, Pick-and-Place ausgelegt. Eckdaten: 6 Freiheitsgrade, erschienen 2025.
The next-generation IRB 1200 is ABB's evolved high-performance small robot family for high-end process applications such as assembly, polishing and dispensing. Powered by ABB's OmniCore controller, it achieves class-leading motion control with path repeatability of 0.03 mm and pose repeatability down to 0.011 mm at speeds up to 1600 mm/s. The family comes in four variants (5, 7, 8 and 9 kg payload) and is 20% lighter than the previous generation.
FUNKTIONEN
- Path repeatability 0.03 mm and pose repeatability 0.011 mm
- Speeds up to 1600 mm/s with class-leading motion control
- 20% lighter than the previous generation
- Four variants: 5, 7, 8 and 9 kg payload
- Up to 24 connection pins for customer power and signal options
- Larger Φ6 x 4 air hose for simultaneous vacuum handling
- Compatible with OmniCore E10, C30, C90XT and V250XT controllers
TECHNISCHE DATEN
Verifiziert| Mobilität | |
| Bewegungsart | Stationär |
|---|---|
| Freiheitsgrade | 6 |
| Manipulation | Hoch |
TECHNISCHE DATEN
Verifiziert| Mobilität | |
| Bewegungsart | Stationär |
|---|---|
| Freiheitsgrade | 6 |
| Manipulation | Hoch |
Bilder
martti
Bildbeiträge
ROBOTER-FOREN
Foren werden geladen...
BEWERTUNGEN
HÄUFIG GESTELLTE FRAGEN
What is the IRB 1200 Next Generation?
The next-generation IRB 1200 is ABB's evolved high-performance small robot family for high-end process applications such as assembly, polishing and dispensing.
Who makes the IRB 1200 Next Generation?
The IRB 1200 Next Generation is made by ABB Robotics, a robotics company based in China.
How much does the IRB 1200 Next Generation cost?
ABB Robotics has not publicly announced pricing for the IRB 1200 Next Generation. You can enquire through RobotAIGeek for current pricing.
What is the IRB 1200 Next Generation used for?
The IRB 1200 Next Generation is designed for montage and pick-and-place. It is used in fertigung settings.
How many degrees of freedom does the IRB 1200 Next Generation have?
The IRB 1200 Next Generation has 6 degrees of freedom.
When was the IRB 1200 Next Generation released?
The IRB 1200 Next Generation was released in 2025.
