描述
RB16-900是Rainbow Robotics的Industrial-Robot。 面向組裝、托盤化、拾放設計。 關鍵數據：32 kg、負載 16 kg、臂展 900 mm、6 自由度。
The RB16-900 is a Rainbow Robotics collaborative robot arm with a 16 kg payload and 900 mm reach, built for safe human-robot cooperation on industrial tasks such as packaging, welding, assembly, and inspection.
功能特色
- In-house engineered high-performance collaborative arm
- globally certified safety (NRTL, CE, KCs / TÜV SÜD — ISO 13849-1 Cat.3 PL d, ISO 10218-1, ISO/TS 15066)
- ±0.05 mm repeatability
- IP-rated operating environment per model
- M8 tool flange
- 5 m robot-arm cable. Model RB16-900: payload 16 kg, reach 900 mm, arm weight 32 kg, footprint Ø 196 mm, operating environment IP66 / 0-50 °C.
技術規格
已驗證| 物理參數 | |
| 重量 | 32 kg |
|---|---|
| 負載 | 16 kg |
| 臂展 | 900 mm |
| 重複定位精度 | ±0.05 mm |
| 移動能力 | |
| 移動類型 | 文具 |
| 自由度 | 6 |
技術規格
已驗證| 物理參數 | |
| 重量 | 32 kg |
|---|---|
| 負載 | 16 kg |
| 臂展 | 900 mm |
| 重複定位精度 | ±0.05 mm |
| 移動能力 | |
| 移動類型 | 文具 |
| 自由度 | 6 |
圖片
martti
圖片貢獻
機器人論壇
正在載入論壇...
評分
常見問題
What is the RB16-900?
The RB16-900 is a Rainbow Robotics collaborative robot arm with a 16 kg payload and 900 mm reach, built for safe human-robot cooperation on industrial tasks such as packaging, welding, assembly, and inspection.
Who makes the RB16-900?
The RB16-900 is made by Rainbow Robotics, a robotics company based in South Korea.
How much does the RB16-900 cost?
Rainbow Robotics has not publicly announced pricing for the RB16-900. You can enquire through RobotAIGeek for current pricing.
What is the RB16-900 used for?
The RB16-900 is designed for 組裝, 托盤化, 拾放, and 焊接. It is used in 製造業 settings.
What is the payload capacity of the RB16-900?
The RB16-900 has a payload capacity of 16 kg and a reach of 900 mm.
How much does the RB16-900 weigh?
The RB16-900 weighs 32 kg.
How many degrees of freedom does the RB16-900 have?
The RB16-900 has 6 degrees of freedom.
