描述
ChangingTek CT-PTSS2000-200是ChangingTek (Zhixing 知行机器人科技有限公司）的Mobile-Robots。 面向運輸、Heavy material transport in factories、production line feeding設計。 關鍵數據：負載 2000 kg。
The CT-PTSS2000-200 is the heavy end of ChangingTek's Composite Robot Series: a multi-stage lifting mobile platform rated to carry two tonnes. At 2,800 by 1,300 mm and only 650 mm tall it is deliberately low-slung, built to drive underneath a load, lift it and move it rather than to carry it on top of a mast. It drives omnidirectionally, so it can translate sideways into position without needing room to turn — the property that matters most when manoeuvring a two-tonne load in a factory aisle. Navigation combines QR-code positioning with inertial navigation and it stops to within ±10 mm, which is tight enough to hand off to fixed automation at the end of a move. Power comes from a 38.5 Ah lithium iron phosphate pack charged from ordinary AC220V 50 Hz mains. It runs under the ChangingOS platform alongside the rest of the series, supporting both single-unit operation and multi-unit scheduling.
功能特色
- 2,000 kg rated load
- 2,800 x 1,300 x 650 mm low-profile chassis designed to drive under and lift a load
- multi-stage lifting mechanism
- omnidirectional driving for sideways positioning without turning room
- QR-code positioning combined with inertial navigation
- stopping accuracy of ±10 mm
- 38.5 Ah lithium iron phosphate battery charged from AC220V 50 Hz mains
- runs the integrated ChangingOS platform with single-unit and multi-unit scheduling.
技術規格
| 物理參數 | |
| 外形尺寸 | L 2.8 m × W 1.3 m × H 650 mm |
|---|---|
| 負載 | 2000 kg |
| 移動能力 | |
| 移動類型 | 帶輪的 |
| 作業環境 | Indoor factory and warehouse floors |
| 致動器 | Omnidirectional drive with a multi-stage lifting mechanism rated to 2,000 kg |
| 電源與續航 | |
| 續航時間 | LiFePO4 38.5 Ah |
| 感知與計算 | |
| 軟體 / AI | ChangingOS integrated control platform with multi-unit scheduling; QR-code plus inertial navigation |
技術規格
| 物理參數 | |
| 外形尺寸 | L 2.8 m × W 1.3 m × H 650 mm |
|---|---|
| 負載 | 2000 kg |
| 移動能力 | |
| 移動類型 | 帶輪的 |
| 作業環境 | Indoor factory and warehouse floors |
| 致動器 | Omnidirectional drive with a multi-stage lifting mechanism rated to 2,000 kg |
| 電源與續航 | |
| 續航時間 | LiFePO4 38.5 Ah |
| 感知與計算 | |
| 軟體 / AI | ChangingOS integrated control platform with multi-unit scheduling; QR-code plus inertial navigation |
圖片
martti
martti
martti
martti圖片貢獻
影片
機器人論壇
正在載入論壇...
評分
常見問題
What is the ChangingTek CT-PTSS2000-200?
The CT-PTSS2000-200 is the heavy end of ChangingTek's Composite Robot Series: a multi-stage lifting mobile platform rated to carry two tonnes. At 2,800 by 1,300 mm and only 650 mm tall it is deliberately low-slung, built to drive underneath a load, lift it and move it rather than to carry it on top of a mast.
Who makes the ChangingTek CT-PTSS2000-200?
The ChangingTek CT-PTSS2000-200 is made by ChangingTek (Zhixing 知行机器人科技有限公司）, a robotics company based in China.
How much does the ChangingTek CT-PTSS2000-200 cost?
ChangingTek (Zhixing 知行机器人科技有限公司） has not publicly announced pricing for the ChangingTek CT-PTSS2000-200. You can enquire through RobotAIGeek for current pricing.
What is the ChangingTek CT-PTSS2000-200 used for?
The ChangingTek CT-PTSS2000-200 is designed for 運輸, heavy material transport in factories, production line feeding, and warehouse pallet and fixture movement. It is used in 汽車, 物流, and 製造業 settings.
What is the payload capacity of the ChangingTek CT-PTSS2000-200?
The ChangingTek CT-PTSS2000-200 has a payload capacity of 2,000 kg.
