描述
C060D是Zhejiang HuaRay Technology的Industrial-Robot。 面向內部物流、舉重、物料搬運設計。 關鍵數據：170 kg、續航 480 分鐘、負載 600 kg。
C060D is iRAYPLE's 600 kg under-ride (latent) lifting AMR: a low 950 x 650 x 300 mm chassis that drives under a rack or cart, lifts it 60 mm and carries it through narrow aisles. It navigates by QR code/texture/laser SLAM, reaches 2.0 m/s empty, stops within ±10 mm and runs 8.0 h per charge (charging: manual/automatic, manually change battery). It talks to iRAYPLE's robot control and scheduling system over Wi-Fi.
功能特色
- Rated load 600 kg
- machine weight 170 kg
- 950 mm×650 mm×300 mm
- Max. speed 2.0 m/s
- Navigation: QR code/texture/laser SLAM
- drive: Two-wheel speed difference
- Lifting Process Distance: 60 mm
- Lifting Pallet Dimensions: 900 mm×560 mm
- Rotation Diameter: 1000 mm
- Stopping accuracy (no load): ±10 mm
- Climbing Ability: 3°/5%
- Obstacle Crossing Height: 10 mm
- Obstacle Avoidance Method: Laser or Laser, TOF (by SKU)
- Charging Mode: Manual/automatic, manually change battery
- Communication Mode: Wi-Fi
- Operating time 8.0 h
- charging 1.5 h
技術規格
已驗證| 物理參數 | |
| 重量 | 170 kg |
|---|---|
| 外形尺寸 | L 950 mm × W 650 mm × H 300 mm |
| 負載 | 600 kg |
| 移動能力 | |
| 移動類型 | 帶輪的 |
| 速度 | 7.2 km/h |
| 作業環境 | Factories and warehouses (indoor, 0-40 C) |
| 電源與續航 | |
| 續航時間 | 480 min |
| 充電類型 | Manual/automatic, manually change battery |
| 感知與計算 | |
| 感測器 | laser navigation/obstacle-avoidance scanners, TOF depth cameras (1T/2T sensor options), downward code camera (QR/DM and floor-texture navigation), collision bumpers |
| 連線方式 | Wi-Fi |
機器人論壇
正在載入論壇...
技術規格
已驗證| 物理參數 | |
| 重量 | 170 kg |
|---|---|
| 外形尺寸 | L 950 mm × W 650 mm × H 300 mm |
| 負載 | 600 kg |
| 移動能力 | |
| 移動類型 | 帶輪的 |
| 速度 | 7.2 km/h |
| 作業環境 | Factories and warehouses (indoor, 0-40 C) |
| 電源與續航 | |
| 續航時間 | 480 min |
| 充電類型 | Manual/automatic, manually change battery |
| 感知與計算 | |
| 感測器 | laser navigation/obstacle-avoidance scanners, TOF depth cameras (1T/2T sensor options), downward code camera (QR/DM and floor-texture navigation), collision bumpers |
| 連線方式 | Wi-Fi |
圖片
martti
martti
martti
martti
martti
martti
martti
martti圖片貢獻
影片
機器人論壇
正在載入論壇...
評分
常見問題
What is the C060D?
C060D is iRAYPLE's 600 kg under-ride (latent) lifting AMR: a low 950 x 650 x 300 mm chassis that drives under a rack or cart, lifts it 60 mm and carries it through narrow aisles.
Who makes the C060D?
The C060D is made by Zhejiang HuaRay Technology, a robotics company based in China.
How much does the C060D cost?
Zhejiang HuaRay Technology has not publicly announced pricing for the C060D. You can enquire through RobotAIGeek for current pricing.
What is the C060D used for?
The C060D is designed for 內部物流, 舉重, 物料搬運, and 運輸. It is used in 汽車, 電子產品, 物流, and 製造業 settings.
What is the payload capacity of the C060D?
The C060D has a payload capacity of 600 kg.
How much does the C060D weigh?
The C060D weighs 170 kg.
How fast is the C060D?
The C060D can move at speeds of up to 7.2 km/h.
What is the battery life of the C060D?
The C060D runs for about 480 minutes on a charge.
