描述
NJ-100-3.2 PRESS是Comau的Industrial-Robot。 面向采摘设计。 关键数据：1250 kg、负载 100 kg、臂展 3209 mm、6 自由度。
Comau's NJ-100-3.2 PRESS is a stationary industrial robot engineered for press handling tasks, forming part of Comau's broad automation lineup that spans collaborative and mobile robotics.
功能特点
- Comau NJ-100-3.2 PRESS is a six-axis press-shop robot for press-to-press automation in cold-stamping and hot-forming lines, delivering coordinated, synchronised cycles.
- Technical specifications (Comau datasheet): maximum wrist payload 100 kg
- additional forearm load 50 kg
- maximum horizontal reach 3209 mm
- repeatability +/-0.17 mm
- robot weight 1250 kg
- 6 axes
- protection IP44 / IP65 Wrist
- mounting Floor.
技术规格
已验证| 物理参数 | |
| 重量 | 1250 kg |
|---|---|
| 负载 | 100 kg |
| 臂展 | 3.21 m |
| 重复定位精度 | ±0.17 mm |
| 移动能力 | |
| 运动类型 | 文具 |
| 自由度 | 6 |
| 操作能力 | 高 |
| 作业环境 | IP44 |
技术规格
已验证| 物理参数 | |
| 重量 | 1250 kg |
|---|---|
| 负载 | 100 kg |
| 臂展 | 3.21 m |
| 重复定位精度 | ±0.17 mm |
| 移动能力 | |
| 运动类型 | 文具 |
| 自由度 | 6 |
| 操作能力 | 高 |
| 作业环境 | IP44 |
martti
martti
martti
martti图片贡献
机器人论坛
正在加载论坛...
评分
常见问题
What is the NJ-100-3.2 PRESS?
Comau's NJ-100-3.2 PRESS is a stationary industrial robot engineered for press handling tasks, forming part of Comau's broad automation lineup that spans collaborative and mobile robotics.
Who makes the NJ-100-3.2 PRESS?
The NJ-100-3.2 PRESS is made by Comau, a robotics company based in Italy.
How much does the NJ-100-3.2 PRESS cost?
Comau has not publicly announced pricing for the NJ-100-3.2 PRESS. You can enquire through RobotAIGeek for current pricing.
What is the NJ-100-3.2 PRESS used for?
The NJ-100-3.2 PRESS is designed for 采摘. It is used in 制造业 settings.
What is the payload capacity of the NJ-100-3.2 PRESS?
The NJ-100-3.2 PRESS has a payload capacity of 100 kg and a reach of 3.21 m.
How much does the NJ-100-3.2 PRESS weigh?
The NJ-100-3.2 PRESS weighs 1,250 kg.
How many degrees of freedom does the NJ-100-3.2 PRESS have?
The NJ-100-3.2 PRESS has 6 degrees of freedom.
