Modular Robot Kits (H1-B / H1-S)是Shanghai PartnerX Robotics (Abilix)的Educational-Robots。 面向娱乐、教育、STEM education: robot building and programming设计。
The Modular series is Abilix's screw-less robot kit: parts snap together with S1-S4 connectors, so children can build a bionic model such as a humanoid, dinosaur, spider or excavator in about 20 minutes. Programming software offers a 3D construction simulator and an action editor that sets movement sequences by clicking and dragging. Electronics include the H-CON101 controller (ARM Cortex-M3, gyroscope, Bluetooth, two stored programs), the H-S100 integrated sensor (distance, light and sound sensors plus buzzer) and H-M24 intelligent motors with 24 kg torque, position/speed/load/current/temperature feedback and an RS-485 bus that chains up to 254 motors. H1-B has 4 servos; H1-S has 18 for a full humanoid.
功能特点
- H1-B: Components 84 pieces
- Actuators 4 Servo Motors
- Brick Types 21
- Sensors 1 Integrated Sensor
- H1-S: Components 218 pieces
- Actuators 18 Servo Motors
- Brick Types 24
- Sensors 1 Integrated Sensor
- Graded programming software
- Abilix curricula and WER contest support
技术规格
已验证| 移动能力 | |
| 运动类型 | 其他 |
|---|---|
| 作业环境 | Homes, classrooms and robotics clubs |
| 执行器 | Kit motors / servos (see features) |
| 感知与计算 | |
| 传感器 | see features |
机器人论坛
正在加载论坛...
技术规格
已验证| 移动能力 | |
| 运动类型 | 其他 |
|---|---|
| 作业环境 | Homes, classrooms and robotics clubs |
| 执行器 | Kit motors / servos (see features) |
| 感知与计算 | |
| 传感器 | see features |
martti
martti
martti图片贡献
视频
机器人论坛
正在加载论坛...
评分
常见问题
What is the Modular Robot Kits (H1-B / H1-S)?
The Modular series is Abilix's screw-less robot kit: parts snap together with S1-S4 connectors, so children can build a bionic model such as a humanoid, dinosaur, spider or excavator in about 20 minutes.
Who makes the Modular Robot Kits (H1-B / H1-S)?
The Modular Robot Kits (H1-B / H1-S) is made by Shanghai PartnerX Robotics (Abilix), a robotics company based in China.
How much does the Modular Robot Kits (H1-B / H1-S) cost?
Shanghai PartnerX Robotics (Abilix) has not publicly announced pricing for the Modular Robot Kits (H1-B / H1-S). You can enquire through RobotAIGeek for current pricing.
What is the Modular Robot Kits (H1-B / H1-S) used for?
The Modular Robot Kits (H1-B / H1-S) is designed for 娱乐, 教育, and stem education: robot building and programming. It is used in 消费者, 教育, and 住宅 settings.
