描述
Cobot Welding Station IMOS-W-I5-350-1000C是AE Robotics Co., Ltd.的Industrial-Robot。 面向组装、焊接设计。 关键数据：350 kg、6 自由度、价格 $28,900。
The IMOS-W-I5-350-1000C is a self-contained collaborative welding cell from AE Robotics, pairing an AUBO six-axis cobot with a 350 A MIG/MAG power source over a 1000 x 1000 mm fixtured welding table. Programs are created by hand-guiding the arm through the joint rather than writing code, so a fabricator can set up a part without robot programming experience, and the whole station arrives on levelling feet ready to be wheeled into a bay.
功能特点
- Integrated collaborative welding cell built on an AUBO six-axis cobot
- Programming-free setup: operator hand-guides (drags) the arm to teach the weld path
- 350 A welding machine capacity, MAG/MIG process
- 1000 x 1000 mm fixtured welding table, 28 mm station apertures on a 100 mm pitch
- Welds carbon steel and stainless steel
- Air-cooled torch
- wire diameters 0.8 / 1.0 / 1.2 mm
- Collision protection fitted as standard
- optional gun cleaner
- Ingress protection IP54
- Input supply 3-phase 5-wire AC 380 V
- Fieldbus: Ethernet, Modbus RTU/TCP, PROFINET
- Station footprint 1280 x 1160 x 1500 mm, mass 350 kg
- Customisable configuration and quick deployment
技术规格
已验证| 物理参数 | |
| 重量 | 350 kg |
|---|---|
| 外形尺寸 | L 1.28 m × W 1.16 m × H 1.5 m |
| 移动能力 | |
| 运动类型 | 文具 |
| 自由度 | 6 |
| 操作能力 | 高 |
技术规格
已验证| 物理参数 | |
| 重量 | 350 kg |
|---|---|
| 外形尺寸 | L 1.28 m × W 1.16 m × H 1.5 m |
| 移动能力 | |
| 运动类型 | 文具 |
| 自由度 | 6 |
| 操作能力 | 高 |
martti
martti图片贡献
机器人论坛
正在加载论坛...
评分
常见问题
What is the Cobot Welding Station IMOS-W-I5-350-1000C?
The IMOS-W-I5-350-1000C is a self-contained collaborative welding cell from AE Robotics, pairing an AUBO six-axis cobot with a 350 A MIG/MAG power source over a 1000 x 1000 mm fixtured welding table.
Who makes the Cobot Welding Station IMOS-W-I5-350-1000C?
The Cobot Welding Station IMOS-W-I5-350-1000C is made by AE Robotics Co., Ltd., a robotics company based in China.
How much does the Cobot Welding Station IMOS-W-I5-350-1000C cost?
The Cobot Welding Station IMOS-W-I5-350-1000C is priced at around $28,900.
What is the Cobot Welding Station IMOS-W-I5-350-1000C used for?
The Cobot Welding Station IMOS-W-I5-350-1000C is designed for 组装 and 焊接. It is used in 制造业 settings.
How much does the Cobot Welding Station IMOS-W-I5-350-1000C weigh?
The Cobot Welding Station IMOS-W-I5-350-1000C weighs 350 kg.
How many degrees of freedom does the Cobot Welding Station IMOS-W-I5-350-1000C have?
The Cobot Welding Station IMOS-W-I5-350-1000C has 6 degrees of freedom.
