BESCHREIBUNG
Underdrive Omnidirectional ist ein Mobile-Robots von Bluepath Robotics. Er ist für Transport ausgelegt. Eckdaten: 1000 kg, 1000 kg Traglast, erschienen 2024.
The Underdrive Omnidirectional is a 1,000 kg-capacity autonomous mobile robot from Bluepath Robotics of Istanbul, Turkey, whose omnidirectional drive lets it approach and leave a pallet or rack from any direction rather than manoeuvring to line up. The 1,850 x 850 x 350 mm low-profile chassis slides under the load and carries it at up to 1.5 m/s, which suits confined factory aisles and high-mix assembly lines where a differential robot would need turning room it does not have. Natural navigation and VDA 5050 compliance let it share a floor and a fleet manager with the rest of the Bluepath range. Source: https://bluepathrobotics.com/product/underdrive-omnidirectional/
FUNKTIONEN
- 1,000 kg payload with full omnidirectional movement — approach and leave from any direction
- Low-profile 1,850 x 850 x 350 mm chassis for confined aisles and high-mix assembly lines
- Up to 1.5 m/s with +/-10 mm docking accuracy
- Natural SLAM navigation — no floor magnets, reflectors or line tape required
- 3D object detection, dynamic map update and safe remote on/off
- VDA 5050 compatible
- scheduled from the Bluepath All-in-One Fleet Manager
- WMS/ERP integration and PLC/IoT interaction with smart charging scheduling
TECHNISCHE DATEN
Verifiziert| Physisch | |
| Gewicht | 1000 kg |
|---|---|
| Abmessungen | L 1.85 m × W 850 mm × H 350 mm |
| Traglast | 1000 kg |
| Mobilität | |
| Bewegungsart | Radbasiert |
| Geschwindigkeit | 5.4 km/h |
| Einsatzumgebung | Indoor factory and warehouse floors shared with people and vehicles |
| Sensorik & Rechenleistung | |
| Software / KI | Bluepath Robotic Software System with All-in-One Fleet Management; automated task management with manual override, shift management |
TECHNISCHE DATEN
Verifiziert| Physisch | |
| Gewicht | 1000 kg |
|---|---|
| Abmessungen | L 1.85 m × W 850 mm × H 350 mm |
| Traglast | 1000 kg |
| Mobilität | |
| Bewegungsart | Radbasiert |
| Geschwindigkeit | 5.4 km/h |
| Einsatzumgebung | Indoor factory and warehouse floors shared with people and vehicles |
| Sensorik & Rechenleistung | |
| Software / KI | Bluepath Robotic Software System with All-in-One Fleet Management; automated task management with manual override, shift management |
Bilder
martti
marttiBildbeiträge
Videos
ROBOTER-FOREN
Foren werden geladen...
BEWERTUNGEN
HÄUFIG GESTELLTE FRAGEN
What is the Underdrive Omnidirectional?
The Underdrive Omnidirectional is a 1,000 kg-capacity autonomous mobile robot from Bluepath Robotics of Istanbul, Turkey, whose omnidirectional drive lets it approach and leave a pallet or rack from any direction rather than manoeuvring to line up.
Who makes the Underdrive Omnidirectional?
The Underdrive Omnidirectional is made by Bluepath Robotics, a robotics company based in Turkey.
How much does the Underdrive Omnidirectional cost?
Bluepath Robotics has not publicly announced pricing for the Underdrive Omnidirectional. You can enquire through RobotAIGeek for current pricing.
What is the Underdrive Omnidirectional used for?
The Underdrive Omnidirectional is designed for transport. It is used in lager & logistik and fertigung settings.
What is the payload capacity of the Underdrive Omnidirectional?
The Underdrive Omnidirectional has a payload capacity of 1,000 kg.
How much does the Underdrive Omnidirectional weigh?
The Underdrive Omnidirectional weighs 1,000 kg.
How fast is the Underdrive Omnidirectional?
The Underdrive Omnidirectional can move at speeds of up to 5.4 km/h.
When was the Underdrive Omnidirectional released?
The Underdrive Omnidirectional was released in 2024.
