BESCHREIBUNG
TX2-140 ist ein Industrial-Robot von Stäubli. Er ist für Montage, Palettieren, Pick-and-Place ausgelegt. Eckdaten: 250 kg, 40 kg Traglast, 1510 mm Reichweite, 6 Freiheitsgrade, erschienen 2021.
TX2-140 is a Stäubli TX2 6-axis industrial robot with a hygienic encapsulated arm, hollow-shaft gearboxes, and modular SIL3-PLe safety options on the CS9 controller for collaborative-capable cells.
FUNKTIONEN
- 40 kg load capacity
- 1510 mm reach at wrist
- ±0.015 mm repeatability (ISO 9283)
- 250 kg arm mass
- IP65 arm (IP67 with pressurization kit)
- NSF H1 food-oil option
- CS9 controller family
- optional modular SIL3-PLe safety functions.
TECHNISCHE DATEN
| Physisch | |
| Gewicht | 250 kg |
|---|---|
| Traglast | 40 kg |
| Reichweite | 1.51 m |
| Wiederholgenauigkeit | ±0.01 mm |
| Mobilität | |
| Bewegungsart | Stationär |
| Freiheitsgrade | 6 |
| Manipulation | Hoch |
TECHNISCHE DATEN
| Physisch | |
| Gewicht | 250 kg |
|---|---|
| Traglast | 40 kg |
| Reichweite | 1.51 m |
| Wiederholgenauigkeit | ±0.01 mm |
| Mobilität | |
| Bewegungsart | Stationär |
| Freiheitsgrade | 6 |
| Manipulation | Hoch |
Bilder
ROBOTER-FOREN
Foren werden geladen...
BEWERTUNGEN
HÄUFIG GESTELLTE FRAGEN
What is the TX2-140?
TX2-140 is a Stäubli TX2 6-axis industrial robot with a hygienic encapsulated arm, hollow-shaft gearboxes, and modular SIL3-PLe safety options on the CS9 controller for collaborative-capable cells.
Who makes the TX2-140?
The TX2-140 is made by Stäubli, a robotics company based in Switzerland.
How much does the TX2-140 cost?
Stäubli has not publicly announced pricing for the TX2-140. You can enquire through RobotAIGeek for current pricing.
What is the TX2-140 used for?
The TX2-140 is designed for montage, palettieren, pick-and-place, and forschung. It is used in forschung and fertigung settings.
What is the payload capacity of the TX2-140?
The TX2-140 has a payload capacity of 40 kg and a reach of 1.51 m.
How much does the TX2-140 weigh?
The TX2-140 weighs 250 kg.
How many degrees of freedom does the TX2-140 have?
The TX2-140 has 6 degrees of freedom.
When was the TX2-140 released?
The TX2-140 was released in 2021.
