Shihe Boiler Water Wall Composite Operation Robot
BESCHREIBUNG
Shihe Boiler Water Wall Composite Operation Robot ist ein Cleaning-Robots von Shihe Technology. Er ist für Reinigung, Inspektion ausgelegt. Eckdaten: 49 kg.
This machine puts Shihe into thermal power, working the water-cooled wall of a coal-fired boiler - the same surface TRI Jitai's crawler inspects, but approached as a composite operation robot combining treatment and measurement rather than inspection alone. It is a compact crawler: 860 x 375 x 385 mm and 49 kg, driven by four 200 W motors at a rated 200 mm/s, crossing non-continuous obstacles up to 5 mm. Total draw is up to 1,000 W from a mains-fed 220 V to 24 V DC supply. The communications choice is the notable one. It runs wired industrial RS-485 over 60 m rather than radio - inside a steel furnace a cable is more dependable than a wireless link, and the tether doubles as the power feed. It is rated IP65.
FUNKTIONEN
- Composite operation on boiler water-cooled wall surfaces
- Dimensions 860 x 375 x 385 mm
- self weight 49 kg
- Drive power 4 x 200 W
- Rated speed 200 mm/s
- Obstacle crossing: non-continuous obstacles up to 5 mm
- Wired industrial RS-485 communication over 60 m
- Mains supply 220 V converted to DC 24 V
- total consumption up to 1,000 W
- Protection rating IP65
TECHNISCHE DATEN
Verifiziert| Physisch | |
| Gewicht | 49 kg |
|---|---|
| Abmessungen | L 860 mm × W 375 mm × H 385 mm |
| Mobilität | |
| Bewegungsart | Radbasiert |
| Geschwindigkeit | 0.72 km/h |
| Manipulation | Niedrig |
| Einsatzumgebung | Inside coal-fired boiler furnaces on water-cooled wall tube surfaces, IP65 |
| Aktoren | Four-motor magnetic-adhesion crawler at a rated 200 mm/s, cable-tethered for power and RS-485 communication |
TECHNISCHE DATEN
Verifiziert| Physisch | |
| Gewicht | 49 kg |
|---|---|
| Abmessungen | L 860 mm × W 375 mm × H 385 mm |
| Mobilität | |
| Bewegungsart | Radbasiert |
| Geschwindigkeit | 0.72 km/h |
| Manipulation | Niedrig |
| Einsatzumgebung | Inside coal-fired boiler furnaces on water-cooled wall tube surfaces, IP65 |
| Aktoren | Four-motor magnetic-adhesion crawler at a rated 200 mm/s, cable-tethered for power and RS-485 communication |
Bilder
martti
Bildbeiträge
Videos
ROBOTER-FOREN
Foren werden geladen...
BEWERTUNGEN
HÄUFIG GESTELLTE FRAGEN
What is the Shihe Boiler Water Wall Composite Operation Robot?
This machine puts Shihe into thermal power, working the water-cooled wall of a coal-fired boiler - the same surface TRI Jitai's crawler inspects, but approached as a composite operation robot combining treatment and measurement rather than inspection alone.
Who makes the Shihe Boiler Water Wall Composite Operation Robot?
The Shihe Boiler Water Wall Composite Operation Robot is made by Shihe Technology, a robotics company based in China.
How much does the Shihe Boiler Water Wall Composite Operation Robot cost?
Shihe Technology has not publicly announced pricing for the Shihe Boiler Water Wall Composite Operation Robot. You can enquire through RobotAIGeek for current pricing.
What is the Shihe Boiler Water Wall Composite Operation Robot used for?
The Shihe Boiler Water Wall Composite Operation Robot is designed for reinigung and inspektion. It is used in energie and fertigung settings.
How much does the Shihe Boiler Water Wall Composite Operation Robot weigh?
The Shihe Boiler Water Wall Composite Operation Robot weighs 49 kg.
How fast is the Shihe Boiler Water Wall Composite Operation Robot?
The Shihe Boiler Water Wall Composite Operation Robot can move at speeds of up to 0.72 km/h.
