BESCHREIBUNG
Comau's NJ-165-3.0 is a stationary industrial arm built for factory automation, supporting collaborative and mobile robotics integration across a range of manufacturing environments.
FUNKTIONEN
- Comau NJ-165-3.0 is a six-axis industrial robot for manufacturing, handling and welding duty, engineered for high uptime and a compact installed footprint
- Technical specifications (Comau datasheet): maximum wrist payload 165 kg
- additional forearm load 50 kg
- maximum horizontal reach 3000 mm
- repeatability +/-0.09 mm
- robot weight 1240 kg
- 6 axes
- protection IP65 / IP67
- mounting Floor / Ceiling.
TECHNISCHE DATEN
Verifiziert| Physisch | |
| Gewicht | 1240 kg |
|---|---|
| Traglast | 165 kg |
| Reichweite | 3 m |
| Wiederholgenauigkeit | ±0.09 mm |
| Mobilität | |
| Bewegungsart | Stationär |
| Freiheitsgrade | 6 |
| Manipulation | Hoch |
| Einsatzumgebung | IP65 / IP67 |
TECHNISCHE DATEN
Verifiziert| Physisch | |
| Gewicht | 1240 kg |
|---|---|
| Traglast | 165 kg |
| Reichweite | 3 m |
| Wiederholgenauigkeit | ±0.09 mm |
| Mobilität | |
| Bewegungsart | Stationär |
| Freiheitsgrade | 6 |
| Manipulation | Hoch |
| Einsatzumgebung | IP65 / IP67 |
Bilder
martti
martti
marttiBildbeiträge
ROBOTER-FOREN
Foren werden geladen...
BEWERTUNGEN
HÄUFIG GESTELLTE FRAGEN
What is the NJ-165-3.0?
Comau's NJ-165-3.0 is a stationary industrial arm built for factory automation, supporting collaborative and mobile robotics integration across a range of manufacturing environments.
Who makes the NJ-165-3.0?
The NJ-165-3.0 is made by Comau, a robotics company based in Italy.
How much does the NJ-165-3.0 cost?
Comau has not publicly announced pricing for the NJ-165-3.0. You can enquire through RobotAIGeek for current pricing.
What is the NJ-165-3.0 used for?
The NJ-165-3.0 is designed for kommissionierung. It is used in fertigung settings.
What is the payload capacity of the NJ-165-3.0?
The NJ-165-3.0 has a payload capacity of 165 kg and a reach of 3 m.
How much does the NJ-165-3.0 weigh?
The NJ-165-3.0 weighs 1,240 kg.
How many degrees of freedom does the NJ-165-3.0 have?
The NJ-165-3.0 has 6 degrees of freedom.
