説明
Dobot CR3ASはDobot RoboticsのCollaborative-Robotです。 ピッキング向けに設計されています。 主な数値：16.5 kg、可搬質量 3 kg、リーチ 620 mm。
Dobot's CR3AS collaborative robot supports small-scale manufacturing and assembly tasks, offering a compact form factor that enables quick deployment in space-limited environments.
特長
- 3 kg maximum payload with a 620 mm working radius.
- Repeatability +/-0.02 mm
- arm weight 16.5 kg.
- SafeSkin capacitive sensing skin detects a person approaching before contact occurs, allowing full speed until someone is near.
- Collaborative operation - designed to work alongside people without fencing.
- Drag-to-teach programming with a graphical interface, so a cell can be reconfigured without a robotics specialist.
- Applications include machine tending, assembly, bin picking, gluing, quality inspection, screwdriving and palletising.
- DOBOT CR3AS.
技術仕様
検証済み| 本体 | |
| 重量 | 16.5 kg |
|---|---|
| 可搬重量 | 3 kg |
| リーチ | 620 mm |
| 移動性能 | |
| 移動方式 | 固定型 |
| マニピュレーション | 高 |
技術仕様
検証済み| 本体 | |
| 重量 | 16.5 kg |
|---|---|
| 可搬重量 | 3 kg |
| リーチ | 620 mm |
| 移動性能 | |
| 移動方式 | 固定型 |
| マニピュレーション | 高 |
画像
ロボットフォーラム
フォーラムを読み込み中...
評価
よくある質問
What is the Dobot CR3AS?
Dobot's CR3AS collaborative robot supports small-scale manufacturing and assembly tasks, offering a compact form factor that enables quick deployment in space-limited environments.
Who makes the Dobot CR3AS?
The Dobot CR3AS is made by Dobot Robotics, a robotics company based in China.
How much does the Dobot CR3AS cost?
Dobot Robotics has not publicly announced pricing for the Dobot CR3AS. You can enquire through RobotAIGeek for current pricing.
What is the Dobot CR3AS used for?
The Dobot CR3AS is designed for ピッキング. It is used in 製造 settings.
What is the payload capacity of the Dobot CR3AS?
The Dobot CR3AS has a payload capacity of 3 kg and a reach of 620 mm.
How much does the Dobot CR3AS weigh?
The Dobot CR3AS weighs 16.5 kg.
